ENGINE MAINTENANCE - 11
LUBRICATION
Throttle Cable
Lubricate pivot points and exposed cable (Figure 11-3)
with SAE 30W-30 engine oil.
CABLE
CLIP
LUBRICATION
POINTS
Figure 11-3 Typical Throttle Cable
Shift Lever
All Velvet Drive Transmissions - Lubricate the detent ball
and holes in shift lever (Figure 11-4) with white grease
(Lubriplate or equivalent).
DIPSTICK
Figure 11-4 Transmission Shift Lever - Velvet Drive
42
BALL JOINT
SHIFT
LEVER
5000
Shift Cable
Lubricate pivot points and exposed cable (Figure 11-5)
with SAE 30W-30 engine oil.
LUBRICATION
POINTS
Figure 11-5 Typical Shift Cable
L510001-13
