ENGINE SPECIFICATIONS - 12

CRUSADER MASTER ENGINE SPECIFICATIONS - 2013
MODEL
Displacement
Bore
Stroke
Compression Ratio
Compression Pressure
WOT Operating RPM
Preferred WOT RPM
Cruising RPM (Max)
Idle RPM (In Gear)
Oil Pressure @
2000 RPM
Minimum Oil Pressure
Spark Plug P/N
Spark Plug Gap
Firing Order
Thermostat
Over-Temperature
Electrical System
Alternator Rating
Ignition Timing
CAM Retard
Battery Rating
70
MP 5.0L
5.0L (305 CID)
3.75 in. (95.0 mm)
3.48 in. (88.3 mm)
9.4:1
130 - 215 psi
4800-5000 (**5000)
4900
3800
650 (Not Adjustable) 650 (Not Adjustable)
25 - 60 psi
(172 - 414 kPa)
6 psi (41.3 kPa)
at Idle
R030010
0.060 in.
1-8-4-3-6-5-7-2 (LH)
1-2-7-5-6-3-4-8 (RH) 1-2-7-5-6-3-4-8 (RH)
FWC 170˚F (76.7˚C) FWC 170˚F (76.7˚C)
200° F (93.3° C)
12 Volt Negative (-)
Ground
70 / 100 Amps
Not Adjustable
15 + 2 degrees
650 CCA (Minimum)
120 Ah
L510001-13
MP 5.7L
5.7L (350 CID)
4.0 in. (101.6 mm)
3.48 in. (88.3 mm)
9.4:1
130 - 215 psi
5000 - 5300 (**5300)
5200
4000
25 - 60 psi
(172 - 414 kPa))
6 psi (41.3 kPa))
at Idle
R030010
0.060 in..
1-8-4-3-6-5-7-2 (LH)
200° F (93.3° C)
12 Volt Negative (-)
Ground
70 / 100 Amps
Not Adjustable
15 + 2 degrees
650 CCA (Minimum)
120 Ah
MP 6.0L
6.0L (366 CID)
4.0007 in. (101.618 mm)
3.622 in. (92.0 mm)
9.67:1
130 - 215 psi
5400 - 5600 (**5600)
5500
4200
650 (Not Adjustable)
25 - 80 psi
(172 - 552 kPa)
6 psi (41.3 kPa)
at Idle
R030011
0.040 in.
1-8-7-2-6-5-4-3 (LH)
NA
FWC 170˚F (76.7˚C)
200° F (93.3° C)
12 Volt Negative (-)
Ground
70 / 100 Amps
Not Adjustable
Not Adjustable
650 CCA (Minimum)
120 Ah
