Shifting Transmission - Crusader 5.0L MPI Instruction Manual

CLEAR
FLOOD
(100%)
FULL
THROTTLE
(WOT)
Figure 5-3 Throttle Position Setting
NOTICE: If the Slave engine fails to start, ensure that
the Sync/Cruise switch is OFF, if equipped, and the
Throttle lever is at the start/idle position.
NOTICE: If engine still fails to start, contact your
Crusader Marine Engines Dealer for service.
8. Check engine oil pressure immediately after
the engine starts. If oil pressure is not within
specifi cations (see Engine Specifi cations),
immediately stop the engine and determine the
cause.
9. Check voltmeter for proper charging system
operation.
10. Check the engine and transmission for fuel, oil,
water and exhaust leaks.
11. Allow the engine to reach normal operating
temperature. Check the temperature gauge
to ensure the engine is operating within the
normal temperature range. If the temperature
is abnormally high, stop the engine immediately
and determine the cause.
OPERATING INSTRUCTIONS - 5

SHIFTING TRANSMISSION

STARTING
OR IDLE
POSITION
Never shift the transmission into or out of gear
unless the throttle is at the idle position. Shifting the
transmission above 1000 RPM can severely damage
the boat, transmission and engine.
1. Set the throttle lever at the idle position.
2. Move the transmission lever completely forward
3. Move the transmission lever completely
4. Move the transmission lever to the center detent
FORWARD
GEAR
L510001-13
CAUTION
to shift into Forward gear.
backward to shift into Reverse gear.
position to shift into Neutral.
NEUTRAL
Figure 5-4 Shift Control
REVERSE
GEAR
29
