18. Cycle the ignition key several times to run the
electric fuel pumps and fi ll the FCC bowl with
fuel. Inspect the drain plug area for leaks.
Correct any leaks prior to operating the engine.
19. Start the engine and inspect for fuel leaks.
Correct any leaks prior to operating the engine
any further.
DO NOT ATTEMPT TO SERVICE ANY OTHER PARTS
ON THIS UNIT.
Primary Fuel Filter
Primary Fuel Filter Element#: R080033
To Drain Contaminants:
Draining the collection bowl: water is heavier than fuel
and will settle to the bottom of the bowl and appear
different in color. In extremely humid conditions, take
a fuel sample (in a clear container) frequently, daily, if
needed and drain as required if water is present.
1. Place a suitable container below the unit to collect the
contaminants.
2. Close the fuel tank valve (if applicable), then loosen/
remove the drain plug (1) at the bottom of the bowl.
Figure 11-16 item 1.
3. Prime the fuel system following the instructions under
Priming the Fuel System.
To Replace the Element:
Element replacement frequency is determined by the
contamination level in fuels. Fuel fl ow to the engine
becomes restricted as the element slowly plugs with
contaminants, resulting in noticeable power loss and/or
hard starting. Replace element annually, or every 50
hours, whichever comes fi rst. Change the element
as soon as possible. Always carry extra replacement
elements as one tank full of excessively contaminated
fuel can plug a fuel fi lter.
Clean any debris or dirt away from the Crusader head/
fi lter joint prior to removal.
1. Place a suitable container below the unit to collect the
contaminants.
2. Close the valve at the fuel tank (if applicable) and
then remove the drain plug (1) to empty the fi lter of
fuel.
3. Spin the Element and Bowl off together (use a strap
wrench on the element), then remove the bowl from
the element (2). Figure 11-16 item 2.
4. Clean the bowl O-ring gland and the sealing surface
of the mounting head free of dirt, debris or gums.
5. Apply clean motor oil to the new seal and to the bowl
ENGINE MAINTENANCE - 11
O-ring supplied with the new element.
6. Place the new seal onto the top of the new element
and the O-ring into the bowl gland.
7. Spin the bowl onto the element, and then fi ll the
element and bowl assembly with clean fuel.
8. Spin the bowl and element onto the head. Tighten
snugly by hand - do not use tools.
9. Prime the fuel system following the instructions under
Priming the Fuel System.
Make sure there are no fuel leaks before closing the
engine hatch.

Priming Fuel System

To prime the fuel system, cycle the ignition key 3 times
using the following procedures:
1. Turn ignition key to ON position for 5 seconds.
2. Turn ignition key OFF.
3. Pause for 10 seconds.
4. Repeat steps 1-3 three times.
Crank the engine until it starts or 30 seconds elapse. If
the engine does not start, repeat the priming procedures.
This unit should only be serviced by a qualifi ed
Crusader Premier technician. Improper use,
installation or servicing may cause an explosion or
fi re resulting in bodily injury, or death. Read and
follow all instructions before proceeding. Run the
engine and check for fuel leaks after installation,
element replacement or draining the bowl. DO NOT
remove the FCC bowl unless servicing the fi lter
element, otherwise contamination or bowl O-ring
swelling may result.
L510001-13
WARNING
WARNING
55
