CANCELLING THE CRUISE SET-POINT
1. Press the Speed Cancel switch.
2. Pull the Master throttle handle back below the set
point.
3. The Cruise Lamp will go OFF indicating that the
operator has full synchronized throttle control
over the engines.
IMPORTANT: ONLY the Cruise speed set-point has
been cancelled. The engines remain in Sync Mode
with the Master throttle handle in control of both engine
speeds. At this point, a new set speed can be selected
or you may use the Resume Mode to go back to the
previous set speed.

RESUME MODE

1. After cancelling Cruise, the previous set speed
may be resumed by pressing the Speed (+)/Res
/ (-) switch (C), to the (+)/Res position.
1. Push the Master throttle handle forward above
the previous Cruise set-point.
EXITING SYNC/CRUISE MODES
1. Press the Syn/Cru Mode switch (A) to OFF.
2. The Sync (D) and Cruise (E) Lamps will go OFF.
3. Return both throttle handles back to the Idle/Start
position.
4. The operator has full individual throttle control
over the engines.
IMPORTANT: Sync/Cruise mode will remain engaged
until both the Master and Slave throttles are returned
below the sync/cruise set point.
FUNCTION
Starting Engines - Syn/Cru Mode Switch (A) OFF
Engines Synchronized - Syn/Cru Mode Switch (A) ON
Engines w/Cruise Speed Set (Switch (B))
Adjust Cruise Set Speed (Switch (C))
Cancel Cruise Set Speed (Switch (B));
Engines Remain Synchronized
Return to Operator's Total Control After
Turning Syn/Cru Mode Switch (A) OFF
SYNC/CRUISE FUNCTION VS. THROTTLE POSITION
L510001-13
OPERATING INSTRUCTIONS - 5
Sync
(D)
ON
(A)
Syn/Cru
OFF
Figure 5-6 Sync/Cruise Control Panel (Typical)
MASTER
THROTTLE
Idle/Start
Under Operator's Control
WOT
WOT
Under Operator's Control
After Throttle is reduced
Below Cruise Set Speed
Idle/Start
Required to Ensure
Cancellation of All
Sync/Cruise Functions
Cruise
(E)
Set (+)/Res
(B) (C)
Speed Speed
Cancel (-)
SLAVE
THROTTLE
Idle/Start
WOT
WOT
WOT
WOT
Idle/Start
Required to Ensure
Cancellation of All
Sync/Cruise Functions
