Futech LINE LASER LL4200 User Manual page 4

Place the laser on a smoother plane within the 4° levelling range
to have a levelled laser line. The LED indicator light [08] will be
green again when the laser is back in its levelling range.
SWITCH ON/OFF LASER LINES
Press the On/off button – Laser line chooser [01] to turn on or off
the horizontal or vertical lines.
· Press one time: Horizontal line will turn off. Only vertical line
is visible.
· Press second time: Vertical line turns off, horizontal line turns
on again.
· Press a third time: Both laser lines will be on.
LL4200 - LL4205
4
>4°
LL5505
>4°
To turn off the laser device, slide the lock switch [05] to the
lock position (left). All laser lines will be switched off and the
pendulum will be blocked.
LOCKED MODE (SLOPE)
With the lock switch [05] in locked position (left), hold the On/off
button – Laser line chooser [01] 2 seconds until both laser lines,
horizontal and vertical, light up. The LED indicator light [08] is
red and the laser lines will flash shortly every 5 seconds to alert
you the laser line is not levelled! In this mode you can use the
laser to set a sloped line. You can tilt the laser level freely in any
direction.
SWITCH ON/OFF LASER LINES
Pressing the On/off button – Laser line chooser [01] allows you
to turn on or off the horizontal or vertical lines.
· Press one time: Horizontal line will turn off. Only vertical line
is visible.
...
· Press second time: Vertical line turns off, horizontal line turns
on again.
...
