- Page 1 USER EN ENGLISH MANUAL Manual in your LL4200 LINE LASER RED language? LL4205 LINE LASER GREEN LL5505 LINE LASER GREEN Check the back cover...
- Page 2 OVERVIEW LL4200 - LL4205 LL5505 RECEIVER ON/OFF POWER SAVE RECEIVER ON/OFF POWER SAVE DEVICE 01 On/off button - Laser Line selector 02 Energy saver - Receiver button (pulse) 03 USB-C charging connector 04 Battery indicator 05 Lock switch - On/off switch 06 ¼”...
-
Page 3: First Time Usage
SAFETY FIRST TIME USAGE Please read the safety instructions is provided in the separate Remove all protection foils. booklet provided with the device before using. NOTE ALWAYS keep the LOCK switch [05] in lock position (left) SELF-LEVELLING MODE during transport or storage to protect the pendulum. Slide the lock switch [05] to the unlocked position (right). - Page 4 LL5505 >4° >4° Place the laser on a smoother plane within the 4° levelling range To turn off the laser device, slide the lock switch [05] to the to have a levelled laser line. The LED indicator light [08] will be lock position (left).
-
Page 5: Energy Saver Mode
· Press a third time: Both laser lines will be on. RECEIVER MODE (PULSE) Only in self-levelling mode, hold the Energy saver - Receiver LL4200 - LL4205 button [02] for about 2 seconds. The receiver mode is now turned on. This means the laser lines can now be detected by a laser receiver. -
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL LL4200 RED LL4205 GREEN LL5505 GREEN Nr. of horizontal lines 1x100° 1x360° Nr. of vertical lines 1x100° Levelling accuracy +/- 3mm/10m Levelling Pendulum leveling Levelling range 4°, ±1° Working range ±15m ±30m ±40m Up to 12h (100%) Up to 3h (100%) Up to 5h (100%) Operating time... -
Page 7: Declaration Of Conformity
DECLARATION OF CONFORMITY Futech (Belgium) declares under its own responsibility that this device: - LL4200 LINE LASER RED - LL4205 LINE LASER GREEN - LL5505 LINE LASER GREEN is in conformity with the standards - EN 61326-1: 2013 - EN 61326-2-2: 2013... - Page 8 USER MANUAL other languages: DANSK ITALIANO DEUTSCH NEDERLANDS ESPAÑOL NORSK EESTI KEEL PORTUGUÊS SUOMEN KIELI SLOVENŠČINA FRANÇAIS SVENSKA ÍSLENSKA Facebook @futechtools LinkedIn futechtools World Wide Web futech-easy.com YouTube @futechtools...
