First Time Usage - Futech LINE LASER LL4200 User Manual

SAFETY
Please read the safety instructions is provided in the separate
booklet provided with the device before using.
NOTE
ALWAYS keep the LOCK switch [05] in lock position (left)
during transport or storage to protect the pendulum.
While the product is in operation, be careful not to expose your
eyes to the emitting laser beam.
Do not disassemble the laser tool. There are no user serviceable
parts inside.
Do not modify the laser in any way. Modifying the tool may
result in hazardous Laser Radiation Exposure.
Class 2 laser radiation, do not stare into beam!
BATTERY
This laser device uses an internal Li-ion battery (see specifica-
tions) that can be charged using the USB-C power connector.
The battery indicator [04] shows 4 green LED lights when fully
charged. The less lights visible, the less power remains in the
battery.
When only one LED light flashes, the power of the device is very
low and it should be charged as soon as possible.

FIRST TIME USAGE

Remove all protection foils.
USE
SELF-LEVELLING MODE
Slide the lock switch [05] to the unlocked position (right). Both
laser lines, horizontal and vertical, will light up. The pendulum
will be released and the laser will self-level. The LED indicator
light [08] is green.
<4°
If the LED indicator light [08] is red and the laser lines flashes,
this means the laser line is not levelled because the position of
the laser is out of the auto levelling range, which is about 4°.
<4°
3
