reading on the manometer do not match use the + or —
button to adjust the display to match.
V.A.C.® Therapy
© If the Target pressure box numbers and pressure
Mode: Continuous
VA. c © Therapy
6. Press the Play button next to the Measured box for
Pressure Calibration (mmHg)
the Target Pressure and an offset value will be
generated.
1, Ambient pressure Measured:
7. Press the Set button to save the 125 calibration
point.
8. Press the QC Checklist button to continue.
Fes octet 9. Disconnect the Pressure Calibration Setup.
10. Reconnect unit for testing based on the Preventive
Maintenance/Unit Setup instructions.
EL
V.A.C.® Therapy "κ |
ЗЫ: bee 11. Press the Advanced QC button on the
ac Checklist
OC Checklist screen.
Status
Export Logs |
NINE E |
| I Upgrade Software
a
em
|
圖 етот | | | M 12. Press the Arrow button displayed next to V.A.C. *
! SE dr Therapy to advance to the "A.C. º Therapy screen.
13. Repeatthe Pressure Accuracy Check.
for next steps (see the Customer Contact Information
@ If the calibration can not be completed contact KCI
section page 30).
15
