- Page 1 SCART to HDMI 1.3 SD to Full HD Scaler Box Operation Manual...
- Page 2 Introduction This scaler Box is designed to display your analog video/R.G.B images on the HDTV with better viewing resolutions. It can upscale any SCART'S input sources to HDMI output with wide-range resolutions. Further, this device also can transfer sounds for user to enjoy both HD images and sounds consistently. Application ...
- Page 3 Operating Functions Controls Front Panel ① POWER selection button - Press the button once to power on the unit, press again to power off. This device has last memory’s function and will record your last input selection. ② AUTO selection button - Press the button to set the device in Auto mode and the device will auto detected HDMI display’s EDID resolution native then the resolution indicator LED will illuminate.
- Page 4 Connection and Installation Output Resolution Chart Specifications Input port SCART Output port HDMI Output resolution 576p, 720p, 1080i, 1080p@ 50/60 Input signal levels Video:1Vp-p, (75Ω) RGB: 0.7 Vp-p(75Ω) Audio L/R: 0.5Vrms Video System NTSC, PAL Audio Sampling Rate 48KHz Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified) Dimensions (mm)
