Installation; Operation - Omcan IC-CN-0350-D Instruction Manual

• Keep the ice dispenser horizontal in all directions after installation (It can be adjusted through the
adjustable foot at the bottom of the machine).
INSTALLATION OF DRAIN PIPE
• For the layout of water supply and drainage pipes, refer to the table below.
Please use our company's supporting drainage accessories.
• The drain pipe must be installed according to the following principles. Any point in the middle of the drain
pipe must not be higher than the drain port of the ice dispenser. Any point in the middle of the drain pipe
must not be higher than the previous point.
POWER SUPPLY
• The power voltage, frequency and capacity applied should be consistent with those on the nameplate.
• The ground terminal of the power supply, socket or plug must be connected and grounded reliably!
• The power supply and cable used need to comply with national or local standards.
• The power voltage fluctuation must not exceed the rated voltage by ± 10%.
USE OF SUPPORTING ICE MAKER (IF REQUIRED)
• For details, refer to our product catalog or consult our sales staff.
CHECK BEFORE USE
• Check whether all accessories have been taken out of the ice dispenser!
• Check whether the ice dispenser has been adjusted properly!
• Check whether the drain pipe has been connected correctly!
• Check whether the size of ice cubes is appropriate (standard size of ice cube: 22mm * 22mm * 22mm)!
• Check whether the plug is reliably connected to the power supply!
• Check whether the ground terminal is reliably connected to the external qualified electrical ground terminal!
• Check whether the power voltage and frequency are the same as those in the nameplate!
Inside diameter of drain pipe (mm)
>15.8 (5/8")
Fall per meter: >3cm
