(1) Contents:
Qty
Part Name
1
Side Step
12
Button Head Socket Cap Bolts Screws
6
Hex Bolt
12
Button Head Socket Cap Bolts Screws
Side Step
Size(mm)
Qty
18
M8*20
12
M8*25
30
M8*25
24
BXG.7000-S
Part Name
Flat Washer
Flat Washer
Split Lock Washer
Flange Hex Lock Nuts
Size(mm)
M8*22*2
M8*16*1.5
M8
M8
Advertisement
Related Manuals for HOOKE ROAD BXG.7000-S
Summary of Contents for HOOKE ROAD BXG.7000-S
- Page 1 BXG.7000-S Side Step (1) Contents: Part Name Size(mm) Part Name Size(mm) Side Step Flat Washer M8*22*2 Button Head Socket Cap Bolts Screws M8*20 Flat Washer M8*16*1.5 Hex Bolt M8*25 Split Lock Washer Button Head Socket Cap Bolts Screws M8*25 Flange Hex Lock Nuts...
- Page 2 (2) Tools required: a. 6mm Hex Bit Socket; b. Drive Socket Ratchet Wrench;...
- Page 3 About 1 hour, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.7000-S), please scan the QR code.
-
Page 4: Driver Side
(4) Installation instruction: Passenger Side Installation Step 1: Open the package, remove the side on the side, distinguish the driver Note: The rear side is longer the the front side, as side and the passenger side. the picture shown. Driver Side Longer Passenger Side Step 2: Assemble the mounting brackets and the driver side side step with the... - Page 5 Step 3: Install the passenger side step into your vehicle with the Button Head Socket Cap Bolts Screws (M8*25), Flat Washer (M8*22*2), Split Lock Washer (M8), Flange Hex Lock Nuts (M8), Hex Bolts (M8*25). Step 4: Repeat the above installation steps in the driver side.
- Page 6 Step 5: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product! Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product.
