Appendix A - Technical Specifications
Appendix A
Identification Cards and Financial Transaction Cards (ISO 7810, ISO 7811, ISO 7812, ISO 7813)
Identification Cards Integrated Circuits with Contacts (ISO/IEC 7816-1, 2, 3, & 4)
EMV ICC Specifications for Payment Systems Version 4.3, L1 Contact and L2 Contact
Encryption: TDEA (3DES)-CBC using DUKPT
FCC Title 47 Part 15 Class B
CE Level B EMC
CE Safety
UR/CUR UL Recognized
MasterCard TQM
California Proposition 65 (California)
IPC-A-610 Class II Assembly
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specifications 1.1, 2.0
Dimensions (L x W x H):
Weight
Supported Mounting Options:
Ingress Protection
EMV Contact Reader:
Status Indicators:
Display Type:
Display Size (viewable area):
Display Resolution:
Keypad:
Certifications:
Tamper Protection:
Code Protection:
mDynamo Weatherized| Insert Secure Card Reader Authenticator | Installation and Operation Manual
Technical Specifications
mDynamo Weatherized Technical Specifications
Reference Standards and Certifications
Physical Characteristics
3.740 in. L x 1.845 in. W x 1.024 in. H (95 mm x 46.86 mm x 26 mm)
1.22 oz. (35g)
Solution-specific enclosure with card slot, screws, and inserts.
IP55
Card Read Characteristics
EMVCo L1 and L2 Contact Reader
User Interface Characteristics
General Status LED (Red/Green)
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Security Characteristics
Not Applicable
Not Applicable
Signed firmware. Any attempt to install unsigned firmware on the
device renders it unusable.
Page 22 of 27 (D998200657-100)
