- Page 1 Opal10GL Series Entry-Level Industrial Ethernet Switch Hardware Installation Manual Publication Date: Apr. 2023 Version: V1.1...
- Page 2 All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of Kyland Corporation. Copyright © 2023 Kyland Technology Co., Ltd.
- Page 3 Before using the device, read this notice carefully for personal and equipment safety. Please keep the manual for further reference. If the device used not according to the specified way by Kyland, the protection provided by the device maybe diminished. A Kyland is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 Note：The security of any system merged with this device is the responsibility of the assembler. In the following cases, please immediately shut down your power supply and contact your Kyland representative: Water gets into the equipment. Equipment damage or shell damage.
- Page 5 La substitution de composants peut rendre ce materiel inacceptable pour les emplacements de Classe I, Division 2. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 6: Table Of Contents
Contents 1 Product Overview .......................1 2 Structure and Interface .......................2 2.1 Front Panel ........................2 2.2 Top Panel ........................3 3 Mounting ..........................4 3.1 Dimension Drawing ......................4 3.2 Mounting Modes and Steps ..................4 3.2.1 DIN-Rail Mounting ....................5 3.2.2 DIN-Rail Dismounting ....................5 4 Connection .........................7 4.1 10/100/1000Base-T(X) Ethernet Port ................7 4.2 1000Base-X SFP slot ....................8 4.3 Grounding ........................ -
Page 7: Product Overview
Product Overview 1 Product Overview Opal10GL industrial Ethernet switches are specially designed for industrial control applications.Opal10GL supports normal-temperature-range and wide-temperature-range models. Opal10G provides two 1000Base-X SFP slots (Gigabit SFP Slot), and eight 10/100/1000Base-T(X) Ethernet ports, or eight 10/100/1000Base-T(X) Ethernet ports ,For details, see the following table. -
Page 8: Structure And Interface
Structure and Interface 2 Structure and Interface Caution： It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure switch performance. 2.1 Front Panel Figure 1 Front Panel (1) Power 1 LED (2) Power 2 LED (3) 10/100/1000Base-T(X) Ethernet Port (4) 10/100/1000Base-T(X) Ethernet Port connection status LED (green) (5) 10/100/1000Base-T(X) Ethernet port speed LED (yellow) -
Page 9: Top Panel
Structure and Interface (9) 1000Base-X SFP slot speed LED (yellow, indicating the speed of the right slot) (10) 1000Base-X SFP slot connection status LED (green, indicating the status of the right slot) 2.2 Top Panel Figure 2 Top Panel... -
Page 10: Mounting
Mounting 3 Mounting 3.1 Dimension Drawing Figure 3 Opal10GL Dimensions for DIN-Rail Mounting (unit: mm) Caution： As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running. -
Page 11: Din-Rail Mounting
Mounting +60℃ for Opal10GL-E series and -40℃ ≤ Tamb ≤ +75℃ for Opal10GL series. No direct sunlight, distant from heat source and areas with strong electromagnetic interference. 3.2.1 DIN-Rail Mounting Step 1: Select the mounting position for the device and guarantee adequate space and heat dissipation. - Page 12 Mounting Figure 5 DIN Rail Dismounting...
-
Page 13: Connection
Connection 4 Connection 4.1 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M, 100M, or 1000M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight-through or cross-over cable. -
Page 14: 1000Base-X Sfp Slot
Connection Wiring Sequence Figure 7 Connection Using Straight-through/Cross-over Cable Note： The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 4.2 1000Base-X SFP slot 1000Base-X SFP slot (Gigabit SFP slot): You can enable data transmission only after inserting an SFP optical module into the slot and connecting cable properly. - Page 15 Connection Figure 8 Gigabit SFP Optical Module An SFP optical module is equipped with LC connector, and each port consists of a TX (transmit) port and an RX (receive) port. To enable communication between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B, as shown in the following figure.
-
Page 16: Grounding
Connection connectors at one end of the fibers. Caution: The device uses laser to transmit signals in fibers. The laser meets the requirements of level 1 laser products. Routine operation is not harmful to your eyes, but do not look directly at the fiber port when the device is powered on. - Page 17 Connection conductors with the insulation locally removed. Additional intermediate connecting parts, other than ferrules, shall not be used. 4-Pin 5.08mm-Spacing Plug-in Terminal Block Figure 11 4-Pin 5.08mm-Spacing Plug-in Terminal Block (socket) Table 4 Pin Definitions of 4-Pin 5.08mm-Spacing Plug-in Terminal Block Pin Number DC Wiring Definition AC Wiring Definition...
- Page 18 Connection Wiring and mounting should meet following specifications. Table 5 Wiring and Mounting Specifications Terminal Type Required Torque Wire Range (AWG) 4.5-5.0 lb-in（BLZ 5.08）&4.4 lb-in（BLZP 5.08HC） Terminal Block Plug 12-26 for WEIDMUELLER terminal block 4.4（M2.5）/6.0（M3.0） lb-in for Degson terminal Terminal Block Plug 12-28 block Terminal Block Plug...
-
Page 19: Leds
LEDs 5 LEDs Table 6 LEDs State Description The power 1 is connected and operates properly. Power 1 LED The power 1 is not connected or operates abnormally. The power 2 is connected and operates properly. Power 2 LED The power 2 is not connected or operates abnormally. 1000M working state (1000Base-TX) 10/100/1000Base-T(X) Ethernet port 10/100M working state (10/100Base-T(X)) or no... -
Page 20: Basic Features And Specifications
53.6mm×135mm×108mm Dimensions(W×H×D) (excluding connectors, DIN rail) Weight: 0.4Kg Environmental Limits -10℃ ≤ Tamb ≤ 60℃ Opal10GL-E series Ambient Temperature -40℃ ≤ Tamb ≤ 75℃ Opal10GL series Storage Temperature -40℃～+85℃ Ambient Relative Humidity 5%～95% (no condensing) MTBF MTBF 6363643h Warranty Warranty... - Page 21 Kyland Technology Co., Ltd. No.901 Floor 8,Building No.2,Shixing Avenue 30#,Shijingshan District,Beijing, 【100041 China】 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
