KYLAND OPAL5L Series Hardware Installation Manual

Entry-level industrial ethernet switch

Advertisement

Quick Links

Opal5L/Opal8L Series Entry-Level Industrial Ethernet
Switch Hardware Installation Manual
Publication Date: Apr. 2023
Version: V1.1
No.: 112020243

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPAL5L Series and is the answer not in the manual?

Questions and answers

Summary of Contents for KYLAND OPAL5L Series

  • Page 1 Opal5L/Opal8L Series Entry-Level Industrial Ethernet Switch Hardware Installation Manual Publication Date: Apr. 2023 Version: V1.1 No.: 112020243...
  • Page 2 All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of Kyland Corporation. Copyright © 2023 Kyland Technology Co., Ltd.
  • Page 3 Before using the device, read this notice carefully for personal and equipment safety. Please keep the manual for further reference. If the device used not according to the specified way by Kyland, the protection provided by the device maybe diminished. A Kyland is not liable to any personal or equipment damage caused by violation of this notice.
  • Page 4  Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland representative:  Water gets into the equipment.  Equipment damage or shell damage.
  • Page 5 emplacements de Classe I, Division 2. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6: Table Of Contents

    Contents 1 Product Overview .......................1 2 Structure and Interface .......................3 2.1 Front Panel ........................3 2.2 Top Panel ........................4 3 Mounting ..........................6 3.1 Dimension Drawing ......................6 3.2 Mounting Modes and Steps ..................8 3.2.1 DIN-Rail Mounting ..................9 3.2.2 DIN-Rail Dismounting ................. 10 4 Connection ........................
  • Page 7: Product Overview

    Product Overview 1 Product Overview Opal5L/Opal8L industrial Ethernet switches are specially designed for industrial control applications. Opal5L/Opal8L supports normal-temperature-range and wide-temperature-range models. Opal5L provides five 10/100Base-T(X) Ethernet ports or one 100Base-X SFP slots,four 10/100Base-T(X) ports;Opal8L provides eight 10/100Base-T(X) Ethernet ports or two 100Base-X SFP slots,six 10/100Base-T(X) ports, For details, see the following table.
  • Page 8 Product Overview PS1-PS2: power LV-LV=24VAC/DC (18-30VAC, 50/60Hz; 12-48VDC), redundant power input) input Note: We reserve the right to amend the product information listed in this table without notice. To obtain the latest information, you can contact our sales or technical support personnel.
  • Page 9: Structure And Interface

    Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure switch performance. 2.1 Front Panel  Opal5L Front Panel Figure 1 Opal5L Front Panel (1) Power 1 LED (2) Power 2 LED (3) 100M SFP interface indicator (4) 10/100Base-X SFP Port connection status LED (green)
  • Page 10: Top Panel

    Structure and Interface Figure 2 Opal8L Front Panel (1) Power 1 LED (2) Power 2 LED (3) 10/100Base-T(X) Ethernet Port (4) 10/100Base-T(X) Ethernet Port connection status LED (green) (5) 100Base-X SFP slot (6) 10/100Base-X Port connection status LED (green) (7) 10/100Base-X Port connection status LED (green) 2.2 Top Panel ...
  • Page 11 Structure and Interface Figure 3 Opal5L Top Panel  Opal8L Top Panel Figure 4 Opal8L Top Panel...
  • Page 12: Mounting

    Mounting 3 Mounting 3.1 Dimension Drawing  Opal5L-5T Figure 5 Opal5L-5T Dimensions for DIN-Rail Mounting (unit: mm)  Opal5L-1SFP4T...
  • Page 13 Mounting Figure 6 Opal5L-1SFP4T Dimensions for DIN-Rail Mounting (unit: mm)  Opal8L-8T Figure 7 Opal8L-8T Dimensions for DIN-Rail Mounting (unit: mm)  Opal8L-2SFP6T...
  • Page 14: Mounting Modes And Steps

    Mounting Figure 8 Opal8L-2SFP6T Dimensions for DIN-Rail Mounting (unit: mm) Caution:  As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running.
  • Page 15: Din-Rail Mounting

    Mounting  No direct sunlight, distant from heat source and areas with strong electromagnetic interference. DIN-Rail Mounting Step 1: Select the mounting position for the device and guarantee adequate space and heat dissipation. Step 2: Insert the connecting seat onto the top of the DIN rail, and push the bottom of the device inward and upward to ensure the DIN rail fits in the connecting seat.
  • Page 16: Din-Rail Dismounting

    Mounting Figure 10 Opal5L-1SFP4T、Opal8L-2SFP6T DIN-Rail Mounting DIN-Rail Dismounting Step 1: As shown in the following figure, press the device downward and move the device in direction 1 until the bottom of the device is detached from the DIN rail. Step 2: Pull the device upward and move the device in direction 2 until the device is removed from the DIN rail completely.
  • Page 17 Mounting  Opal5L-1SFP4T、Opal8L-2SFP6T DIN Rail Dismounting 、 Figure 12 Opal5L-1SFP4T Opal8L-2SFP6T DIN Rail Dismounting...
  • Page 18: Connection

    Connection 4 Connection 4.1 10/100Base-T(X) Ethernet Port 10/100Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M or 100M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight-through or cross-over cable.
  • Page 19: 100Base-X Sfp Slot

    Connection Figure 14 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 4.2 100Base-X SFP Slot 100Base-X SFP slot: You can enable data transmission only after inserting an SFP optical module into the slot and connecting cable properly.
  • Page 20 Connection Figure 15 100M SFP Optical Module 100M SFP optical module is equipped with LC connector, and each port consists of a TX (transmit) port and an RX (receive) port. To enable communication between Device A and Device B, connect the TX (transmit) port of Device A to the RX (receive) port of Device B, and the RX (receive) port of Device A to the TX (transmit) port of Device B.
  • Page 21: Grounding

    Connection  The device uses laser to transmit signals in fibers. The laser meets the requirements of level 1 laser products. Routine operation is not harmful to your eyes, but do not look directly at the fiber port when the device is powered on. ...
  • Page 22 Connection than ferrules, shall not be used.  4-Pin 5.08mm-Spacing Plug-in Terminal Block Figure 18 4-Pin 5.08mm-Spacing Plug-in Terminal Block (socket) Table 4 Pin Definitions of 4-Pin 5.08mm-Spacing Plug-in Terminal Block Pin Number DC Wiring Definition AC Wiring Definition PWR1: - PWR1: N PWR1: + PWR1: L...
  • Page 23 Connection Table 5 Wiring and Mounting Specifications Terminal Type Required Torque Wire Range (AWG) 4.5-5.0 lb-in(BLZ 5.08)&4.4 lb-in(BLZP 5.08HC) Terminal Block Plug 12-26 for WEIDMUELLER terminal block 4.4(M2.5)/6.0(M3.0) lb-in for Degson terminal Terminal Block Plug 12-28 block Terminal Block Plug 6.2 lb-in(TLPS(@21))for Tianli terminal block 12-30 Terminal Block Plug...
  • Page 24: Leds

    LEDs 5 LEDs Table 6 LEDs State Description The power 1 is connected and operates properly. Power 1 LED The power 1 is not connected or operates abnormally. The power 2 is connected and operates properly. Power 2 LED The power 2 is not connected or operates abnormally.
  • Page 25: Basic Features And Specifications

    Basic Features and Specifications 6 Basic Features and Specifications Power Supply Power Identifier Range 24VAC/DC(18-30VAC, 50/60Hz; 12-48VDC) Terminal Block 4-Pin 5.08mm-Spacing Plug-in Terminal Block Rated Power Consumption Opal5-5T< 2.0W (MAX) Opal5-1SFP4T<2.4W (MAX) Rated Power Consumption Opal8-8T<2.2W (MAX) Opal8-2SFP6T<3.4 W (MAX) Physical Characteristics Housing Metal, fanless...
  • Page 26 Basic Features and Specifications -40℃ ≤ Tamb ≤ 75℃ Opal5L series, Opal8L series Storage Temperature -40℃~+85℃ Ambient Relative Humidity 5%~95% (no condensing) Pollution degree Altitude 2000m MTBF Opal5-5T:5777888h Opal5-1SFP4T:8502760h MTBF Opal8-8T:6106558h Opal8-2SFP6T:8301541h Warranty Warranty Five years...
  • Page 27 Kyland Technology Co., Ltd. No.901 Floor 8,Building No.2,Shixing Avenue 30#,Shijingshan District,Beijing, 【100041 China】 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
