Page 3
Before using the device, read this notice carefully for personal and equipment safety. Please keep the manual for further reference. If the device used not according to the specified way by Kyland, the protection provided by the device maybe diminished. A Kyland is not liable to any personal or equipment damage caused by violation of this notice.
Page 4
Note:The security of any system merged with this device is the responsibility of the assembler. In the following cases, please immediately shut down your power supply and contact your Kyland representative: Water gets into the equipment. Equipment damage or shell damage.
Page 5
La substitution de composants peut rendre ce materiel inacceptable pour les emplacements de Classe I, Division 2. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Product Overview 1 Product Overview Opal8GL industrial Ethernet switches are specially designed for industrial control applications.Opal8GL supports normal-temperature-range and wide-temperature-range models. The series switches support DIN rail mounting.Opal8GL provides two 1000Base-X SFP slots (Gigabit SFP Slot), and eight 10/100/1000Base-T(X) Ethernet ports. For details, see the following table.
Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure switch performance. 2.1 Front Panel Figure 1 Front Panel (1) Power 1 LED (2) Power 2 LED (3) 10/100/1000Base-T(X) Ethernet Port (4) 10/100/1000Base-T(X) Ethernet Port connection status LED (green) (5) 10/100/1000Base-T(X) Ethernet port speed LED (yellow)
Mounting 3 Mounting 3.1 Dimension Drawing Figure 3 Opal8GL Dimensions for DIN-Rail Mounting (unit: mm) Caution: As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running.
Customer shall insure device working in the right ambient temperature, -10℃ ≤ Tamb ≤ +60℃ for Opal8GL-E series and -40℃ ≤ Tamb ≤ +75℃ for Opal8GL series. No direct sunlight, distant from heat source and areas with strong electromagnetic interference.
Page 12
Mounting from the DIN rail completely. Figure 5 DIN Rail Dismounting...
Connection 4 Connection 4.1 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M, 100M, or 1000M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight-through or cross-over cable.
Connection Wiring Sequence Figure 7 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 4.2 Grounding Grounding protects the device from lightning and interference.
Page 15
Connection power wires to the terminal block to provide power for the device. The switch supports redundant power supply with 4-pin 5.08mm-spacing plug-in terminal block. When one power input is faulty, the switch can continue operating properly, thereby improving network reliability.
Page 16
Connection Step 3: Insert the power wires into the power terminal block according to Table 3 and secure the wires. Step 4: Insert the terminal block with the connected wires into the terminal block socket on the device. Step 5: Connect one end of the power cable to an external power supply system (with the allowed power range).
Page 17
Connection sign, because it may cause personal injury. Do not remove any part or plug in or out any connector when the device is powered on.
LEDs 5 LEDs Table 5 LEDs State Description The power 1 is connected and operates properly. Power 1 LED The power 1 is not connected or operates abnormally. The power 2 is connected and operates properly. Power 2 LED The power 2 is not connected or operates abnormally. 1000M working state (1000Base-TX) 10/100/1000Base-T(X) Ethernet port 10/100M working state (10/100Base-T(X)) or no...
