- Page 1 SICOM6800-D Industrial Ethernet Switch Hardware Installation Manual Publication Data: Jan. 2024 Version: V1.0...
- Page 2 All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of KYLAND Corporation. Copyright © 2024 Kyland Technology Co., Ltd.
- Page 3 Before using the device, read this manual carefully for personal and equipment safety. Please keep the manual for further reference. Kyland is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland representative: Water gets into the equipment. Equipment damage or shell damage.
- Page 5 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 6: Table Of Contents
Contents 1 Product Overview ....................... 1 2 Structure and Interface ....................... 2 2.1 Front Panel ........................2 2.2 Top Panel ........................3 Low voltage（L2）products Top Panel ...............3 High voltage（HV）products Top Panel ..............3 3 Mounting ..........................4 3.1 Dimension Drawing ......................4 3.2 Mounting Modes and Steps .................. -
Page 7: Product Overview
Product Overview 1 Product Overview SICOM6800-D is a Layer3 network management Ethernet switch designed for high industrial control safety requirements.It adopts autonomous controllable exchange chip and autonomous controllable CPU.It provides four 1000Base-X, SFP slots (Gigabit SFP Slot), and eight 10/100/1000Base-T(X) Ethernet ports. For details, see the following table. -
Page 8: Structure And Interface
Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure device performance. 2.1 Front Panel Figure 1 Front Panel (1) Power 1 LED (2) Power 2 LED (3) Running LED (4) Ring LED (5) Alarm LED... -
Page 9: Top Panel
Structure and Interface (11) 1000Base-X SFP Slot (12) 10/100/1000Base-T(X) Ethernet Port speed LED (yellow) (13) 10/100/1000Base-T(X) Ethernet Port connection status LED (green) (14) 10/100/1000Base-T(X) Ethernet Port 2.2 Top Panel Low voltage（L2）products Top Panel Figure 2 Low voltage products Top Panel ... -
Page 10: Mounting
Connection 3 Mounting 3.1 Dimension Drawing Figure 4 Dimensions for DIN-Rail Mounting (unit: mm) Caution: As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running. -
Page 11: Din-Rail Mounting
Connection 6) Devices should be installed and accessed by service personnel or users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken. 3.2.1 DIN-Rail Mounting DIN-Rail Mounting Step 1: Select the mounting position for the device and guarantee adequate space and heat dissipation. - Page 12 Connection Figure 6 DIN-Rail Dismounting...
-
Page 13: Connection
Connection 4 Connection 4.1 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M, 100M, or 1000M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight-through or cross-over cable. -
Page 14: 1000Base-X, Sfp Slot
Connection Figure 8 Connection Using Straight-through/Cross-over Cable Note： The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 4.2 1000Base-X, SFP slot 1000Base-X, SFP slot (gigabit SFP slot) requires an SFP optical/electrical module to enable data transmission. -
Page 15: Gigabit Sfp Optical Module
Connection 4.2.1 Gigabit SFP Optical Module Figure 9 Gigabit SFP Optical Module An SFP optical module is equipped with LC connector, and each port consists of a TX (transmit) port and an RX (receive) port. To enable communication between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B, as shown in the following figure. -
Page 16: Gigabit Sfp Electrical Module
Connection If the LED is on, the connection is correct. If the LED is off, the link is not connected. This may be caused by incorrect connection of the TX and RX ports. In this case, swop the two connectors at one end of the fibers. Caution: ... - Page 17 Connection Connect the 9-pin serial port of a PC to the console port of the switch with a DB9-RJ45 console cable. You can configure, maintain, and manage the switch by running Hyper Terminal in the Windows OS of a computer. Figure 14 Console Port ...
-
Page 18: Grounding
Connection Way2: Use a standard RJ45 network cable to connect the network port of the PC and the console port of the device, and configure and manage the device through the web. 4.4 Grounding Grounding protects the switch from lightning and interference. Therefore, you must ground the switch properly. - Page 19 Connection Figure 16 3-Pin 7.62mm-Spacing Plug-in Terminal Block (socket) Table 5 Pin Definitions of 3-Pin 7.62mm-Spacing Plug-in Terminal Block Signal DC Definition AC Definition PWR：+ PWR：L PWR：- PWR：N PGND PGND 5-Pin 5.08mm-Spacing Plug-in Terminal Block Figure 17 5-Pin 5.08mm-Spacing Plug-in Terminal Block (socket) Table 6 Pin Definitions of 5-Pin 5.08mm-Spacing Plug-in Terminal Block Signal DC Definition...
-
Page 20: Alarm Terminal Block
Connection Step 1: Ground the device properly according to section 4.4. Step 2: Remove the power terminal block from the device. Step 3: Insert the power wires into the power terminal block according to and secure the wires. Step 4: Insert the terminal block with the connected wires into the terminal block socket on the device. - Page 21 Connection open and the normally-closed contacts are closed. The alarm is outputted through a 3-pin 5.08mm-spacing plug-in terminal block. Figure 18 Alarm Terminal Block (socket) Electrical parameters of the relay: Max Switch Voltage: 250VAC/220VDC; Max Switch Current: 2A Max Switching Power: 60W Dielectric Strength: 2KV Note：...
-
Page 22: Reset
Reset 5 Reset The device provides a Reset button on the front panel. The button can be used to restart the device or restore factory default settings. You can restart the device by pressing and holding the button for 0.5 to 3 second. You can restore factory default settings by pressing and holding the button for 3 seconds or more. -
Page 23: Leds
LEDs 6 LEDs Table 9 Front Panel LEDs State Description Power 1 is connected and operates properly. Power 1 LED Power 1 is not connected or operates abnormally. Power 2 is connected and operates properly. Power 2 LED Power 2 is not connected or operates abnormally. Blinking The CPU operates properly. - Page 24 LEDs (green) No effective port connection...
-
Page 25: Switch Access
Switch Access 7 Switch Access You can access the switch in any of the following ways: 7.1 Access through Console Port Step 1: Connect the console port of the switch to the 9-pin serial port of a PC with the delivered DB9-RJ45 console cable. - Page 26 Switch Access Figure 20 Selecting a Serial Port Note： To confirm the communication port in use, right-click [My Computer] and select [Property]. Click [Hardware] → [Device Manager] → [Port] to view the communication port. Step 5: Set port parameters (Bits per second: 115200, Data bits: 8, Parity: None, Stop bits: 1, and Flow control: None), as shown in the following figure.
-
Page 27: Access Through Telnet
Switch Access Figure 21 Setting Port Parameters Step 6: Click OK to enter the switch CLI. Then the following commands can be used to perform operations. Table 10 CLI Commands View Command Description Privileged mode SWITCH#show interface vlan 1 Query the IP address of the switch. Privileged mode SWITCH#show version Query the version of the switch. -
Page 28: Access Through Web
Switch Access IP address of the device), enter "telnet 192.168.0.2" in the dialog box. Figure 22 Access through Telnet Step 3: Click OK. The Telnet CLI is displayed. Then you can run the commands in Figure 22 to perform operations. 7.3 Access through Web Step 1: Connect the network port of a PC to the Ethernet port of the switch with a network cable. -
Page 29: Basic Features And Specifications
Basic Features and Specifications 8 Basic Features and Specifications Power Requirements Maximum Voltage Power Identifier Rated Voltage Range Range 24-48VDC 18-72VDC 100-240VAC, 50/60Hz; 85-264VAC/77-300VDC 110-220VDC L2：5-pin 5.08mm-spacing plug-in terminal block Terminal block HV：3-pin 7.62 mm-spacing plug-in terminal block Rated Power Consumption Rated power 20W (MAX) - Page 30 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
