ICON LevelPro ITC 450 Series Quick Start Manual page 3

LevelPro — ITC 450 & 350 Series
®
Tank Level Display + Controller
Features
Super 'Sunbright'
LED Display
8 Levels of Brightness
ITC 450
4 Configurable
(5 AMP) Relays
Function of Push Buttons
24-0352 © Icon Process Controls Ltd.
Rugged
Panel Mount
Design
Optional Remote
1 Configurable
(5A) Relay
Symbol used in the manual : [ESC/MENU]
Functions:
• Enter to main menu (press and hold for at least 3 sec.)
• Exit the current Screen and Enter to previous menu (or measure mode)
• Cancel the changes made in parameter being edited
Symbol used in the manual : [ENTER]
Functions:
• Start to edit the parameter
• Enter into the sub-menu
• Confirmation of changes made in parameter being edited
Symbol used in the manual : [ ] [ ]
Functions:
• Change of the present menu
• Modification of the parameter value
• Change of the display mode
24VDC
Power Supply
to Sensor
Push Button
Programming
ENC-100 NEMA 4X Enclosure
+ ITC 450 Display (Optional)
LP100
Junction Box
AL
R1
R2
R3
R4
R
4-20mA
ITC 450 Display +
ENC-100 Enclosure
(Optional)
100 Series
Submersible
Level Sensor
ITC 350
ESC
ENTER
MENU
