LevelPro — ITC 450 & 350 Series
®
Tank Level Display + Controller
RS485 Modbus Programming
Parameter
Hi r
Omod
OUtL
OUtH
Lo r
Hi r
AL
bri
modE
PEA
timE
HdiS
H r1
H r2
HOut
A r1
A r2
Addr
bAud
mbAc
mbtO
rESP
Edit
24-0352 © Icon Process Controls Ltd.
Description
Extension of the top of the nominal input range
Current output configuration ("OUtP" menu)
Current output mode
Display value for 4 mA current output
Display value for 20 mA current output
Extension of the bottom of the nominal output
range
Extension of the top of the nominal output range
Current output value on critical exception
Display brightness
Configuration of peaks detection function ("HOLd" menu)
Kind of detected changes
Minimum detected change
Maximum time of peak displaying
The type of displayed value
Source of relay R1, and LED R1 control
Source of relay R2, and LED R2 control
Source of current output control
Settings of access to the configuration parameters ("SECu" menu)
Permission to changes of relay R1 threshold
without of the user password knowledge
Permission to changes of relay R2 threshold
without of the user password knowledge
RS 485 interface configuration (menu "rS")
Device address
Baud rate
Permission to changes of configuration registers
Maximum delay between received messages
Additional delay of answer transmission
Configuration of numerical parameters edition
Numerical parameters edit mode
Default value
5.0 (%)
„4-20" (mA)
100.0
5.0 (%)
5.0 (%)
22.1 (mA)
Display parameters
HOLd
Desc.
User's value
page
0.0
bri6
norm
0.0
0.0
rEAL
rEAL
rEAL
on
on
0
9.6
on
0
Std
dig
35
37
37
37
38
38
38
38
39
39
39
39
39
39
39
39
39
40
40
40
40
40
41
25
