ICON LevelPro ITC 450 Series Quick Start Manual page 19

LevelPro — ITC 450 & 350 Series
®
Tank Level Display + Controller
RS485 Modbus Programming
Register Write
34h
35h
36h
37h
38h
39h
3Ah
3Bh
3Ch
3Dh
3Eh
3Fh
50h
51h
52h
53h
54h
55h
1
58h
5
70h
5
71h
24-0352 © Icon Process Controls Ltd.
Range
"toFF" parameter in "rEL1" menu, expressed in tenth of seconds
Yes 0 ÷ 999
or tenth of minutes depend on "unit" parameter - register no. 35h)
"unit" parameter in "rEL1" menu:
Yes 0 ÷ 1
0 - seconds; 1 - minutes
Yes 0 ÷ 2 "AL" parameter in "rEL1" menu: 0 - no changes; 1 - on; 2 - off
Yes -999 ÷ 9999
"SEt2" parameter in "rEL1" menu, no decimal point included
Yes -999 ÷ 9999 "SEtP" parameter in "rEL2" menu, no decimal point included
Yes -999 ÷ 999
"HySt" parameter in "rEL2" menu, no decimal point included
"modE" parameter in "rEL2" menu:
Yes 0 ÷ 5 0 - "noAC" mode; 1 - "on" mode; 2 - "oFF" mode; 3 - "in" mode;
4 - "out" mode; 5 - "modb" mode
"t on" parameter in "rEL2" menu, expressed in tenth of seconds or
Yes 0 ÷ 999
tenth of minutes depend on "unit" parameter - register no. 3Dh)
"toFF" parameter in "rEL2" menu, expressed in tenth of seconds
Yes 0 ÷ 999
or tenth of minutes depend on "unit" parameter - register no. 3Dh)
"unit" parameter in "rEL2" menu:
Yes 0 ÷ 1
0 - seconds; 1 - minutes
Yes 0 ÷ 2 "AL" parameter in "rEL2" menu: 0 - no changes; 1 - on; 2 - off
Yes -999 ÷ 9999 "SEt2" parameter in "rEL2" menu, no decimal point included
"modE" parameter in "HOLd" menu (type of detected changes):
Yes 0 ÷ 1
0 - peaks; 1 - drops
"PEA" parameter in "HOLd" menu (minimum detectable change, no
Yes 0 ÷ 9999
decimal point included)
"timE" parameter in "HOLd" menu,
Yes 0 ÷ 199
display time expressed in seconds
"HdiS" parameter in "HOLd" menu:
Yes 0 ÷ 1
0 - "rEAL" mode ; 1 - "HOLd" mode
"H r1" parameter in "HOLd" menu
Yes 0 ÷ 1
0 - "rEAL" mode ; 1 - "HOLd" mode
"H r2" parameter in "HOLd" menu:
Yes 0 ÷ 1
0 - "rEAL" mode ; 1 - "HOLd" mode
"HOut" parameter in "HOLd" menu:
Yes 0 ÷ 1
0 - "rEAL" mode ; 1 - "HOLd" mode
The value of „X" coordinate of point no. 1 of the user defined
Yes -999 ÷ 1999
characteristic, expressed in 0.1%
The value of „Y" coordinate of point no. 1 of the user defined
Yes -999 ÷ 9999
characteristic, no decimal point included
Further pairs of „X" - „Y" coordinates of points no. 2 ÷ 19 of the
5 5
72h ÷ 95h
user defined characteristic
Register description
maximum peaks' (or drops')
:
