LevelPro

— ITC 450 & 350 Series

Tank Level Display + Controller

Quick Start Manual

Read the user's manual carefully before starting to use the

unit or software. Producer reserves the right to implement

changes without prior notice.

24-0352

Need help?

Do you have a question about the LevelPro ITC 450 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ICON LevelPro ITC 450 Series

Page 1 — ITC 450 & 350 Series ® Tank Level Display + Controller Quick Start Manual Read the user's manual carefully before starting to use the unit or software. Producer reserves the right to implement changes without prior notice. 24-0352 © Icon Process Controls Ltd.
Page 2 Output Part Number Input Output ITC 450-1121 ITC 350-1119 4-20 mA 4 Relay 4-20 mA ITC 450-1129 4-20 mA 4-20 mA + 2 Relay ITC 350-1120 4-20 mA 4-20 mA + 1x (5A) Relay 24-0352 © Icon Process Controls Ltd.
Page 3 Confirmation of changes made in parameter being edited Symbol used in the manual : [ ] [ ] Functions: • Change of the present menu • Modification of the parameter value • Change of the display mode 24-0352 © Icon Process Controls Ltd.
Page 4 • Tighten set screw In the case of using a monopolar fuse it must be mounted on the phase cable. • Replace wire terminal into socket Figure D. Minimum distances when assembly of a number of units 24-0352 © Icon Process Controls Ltd.
Page 5 Figure 4.8. Terminals description (relay and active current outputs) Figure 4.8. Terminals description (relay and active current outputs) www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www. levelprosales.com www. levelprosales.com www. levelprosales.com 24-0352 © Icon Process Controls Ltd.
Page 6 Figure 4.9. Terminals description (OC-type and active current outputs) Figure I. — Terminals description (relay and passive current outputs) Figure J. — Terminals description (OC-type and passive current outputs) www.iconprocon.com | sales@iconprocon.com | 905.469.9283 24-0352 © Icon Process Controls Ltd. www. levelprosales.com www.iconprocon.com | sales@iconprocon.com | 905.469.9283...
Page 7 Figure K. — Terminals description (relay and active voltage outputs) Figure L. — Terminals description (OC-type and active voltage outputs) Figure M. — Connection of 2-wire current converters www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www.iconprocon.com | sales@iconprocon.com | 905.469.9283 24-0352 © Icon Process Controls Ltd. www. levelprosales.com www. levelprosales.com...
Page 8 Ra, Rb, Rc, Rd can be different Ra, Rc can be different Ra = Rc = Rd www. levelprosales.com Figure 4.17. Connection of RTD sensors: 24-0352 © Icon Process Controls Ltd. a) 4-wires circuit; b) 3-wires circuit; c) 2-wires circuit...
Page 9 Figure R. — Examples of suppression circuit connection: a) to relay terminals; b) to the inductive load www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www. levelprosales.com 24-0352 © Icon Process Controls Ltd.
Page 10 | sales@iconprocon.com | 905.469.9 www. levelprosales.com Figure V. — Example of active voltage outputs connection (for device with active output only) www.iconprocon.com | sales@iconprocon.com | 905.469.9283 www. levelprosales.com www.iconprocon.com | sales@iconprocon.com | 905.469.9283 24-0352 © Icon Process Controls Ltd. www. levelprosales.com...
Page 11 Enter HIGH C | 20mA Set 20mA Value ▶ Press to change digit �� Press to advance to next digit 2 Sec. Save Value ▶ SAVE SELECTION Return to Main Display ▶ Return to MAIN DISPLAY 24-0352 © Icon Process Controls Ltd.
Page 12 Enter OUTPUT High | 20mA Set 20mA Value ▶ Press to change digit �� Press to advance to next digit 2 Sec. Save Value ▶ SAVE SELECTION Return to Main Display ▶ Return to MAIN DISPLAY 24-0352 © Icon Process Controls Ltd.
Page 13 2 Sec. Return to Main Display ▶ Save Selection Return to Main Display ▶ Press Button (2x) (Home Screen | Current Level Reading appears on display) Save Value ▶ 24-0352 © Icon Process Controls Ltd.
Page 14 6000 gallons and shuts off at 1000 gallons. If at any time the active pump can’t keep the level below 7000 gallons, the other pump would come on as well. Pump Al ternation Control Operation 24-0352 © Icon Process Controls Ltd.
Page 15 6000 6000 Control Relay Control Relay gallons, relay #2 starts the backup pump. 1000 Pump 100 Series Main Pump Level Sensor 1000 100 Series Main Pump Level Sensor Backup Pump Backup Pump Backup Pump 24-0352 © Icon Process Controls Ltd.
Page 16 7000 6000 rol Relay Control Relay Control Relay Control Relay When the level falls below 1000 gallons, both pumps will turn off. 1000 Pump Main Pump 100 Series Level Sensor Backup Pump Backup Pump 24-0352 © Icon Process Controls Ltd.
Page 17 0 ÷ 5 characteristics of a cylindrical tank in the vertical position; 5 - volume characteristics of a cylindrical tank in the horizontal position 0 ÷ 5 “FiLt” parameter in “InPt” menu (measurement filtering rate) 24-0352 © Icon Process Controls Ltd.
Page 18 4 - “out” mode; 5 - “modb” mode “t on” parameter in “rEL1” menu, expressed in tenth of seconds or 0 ÷ 999 tenth of minutes depend on “unit” parameter - register no. 35h) 24-0352 © Icon Process Controls Ltd.
Page 19 The value of „Y” coordinate of point no. 1 of the user defined -999 ÷ 9999 characteristic, no decimal point included Further pairs of „X” - „Y” coordinates of points no. 2 ÷ 19 of the ÷ 95h user defined characteristic 24-0352 © Icon Process Controls Ltd.
Page 20 „X” coordinate of this point is equal 8000h. After writing both X and Y coordinate the point is defined and used in calculation of result. The coordinates of any point can be changed at any time. 24-0352 © Icon Process Controls Ltd.
Page 21 The answer (we assume that the measure result is not out of range): ADDR FUNC BYTE C DATA H,L CRC L,H DATA H, L - displayed value = 255, no decimal point. Decimal point position can be read from reg. 03h. 24-0352 © Icon Process Controls Ltd.
Page 22 4. Change of baud rate of all devices connected to the net (BROADCAST message). ADDR FUNC REG H,L COUNT H,L CRC L,H DATA H - 0 DATA L - 4, new baud rate 19200 baud Device do not reply to BROADCAST-type messages. 24-0352 © Icon Process Controls Ltd.
Page 23 - reg. 02h (0 - no errors),, DATA H3, L3 - reg. 03h (1 - decimal point position ” 0.0”). There is no full implementation of the Modbus Protocol in the device. The functions presented above are available only. 24-0352 © Icon Process Controls Ltd.
Page 24 Tank diameter 00.01 t Sn Distance between sensor and bottom of the tank 00.00 t Sh Height of the sensor 20.00 Lo r Extension of the bottom of the nominal input range 5.0 (%) 24-0352 © Icon Process Controls Ltd.
Page 25 Device address bAud Baud rate mbAc Permission to changes of configuration registers mbtO Maximum delay between received messages rESP Additional delay of answer transmission Configuration of numerical parameters edition Edit Numerical parameters edit mode 24-0352 © Icon Process Controls Ltd.
