LevelPro — ITC 450 & 350 Series
®
Tank Level Display + Controller
Symbol Explanation
This symbol denotes especially important guidelines concerning the installation and operation of the device. Not complying
with the guidelines denoted by this symbol may cause an accident, damage or equipment destruction.
Basic Requirements | User Safety
■ Do not use the unit in areas threatened with excessive shocks, vibrations, dust, humidity,
corrosive gasses and oils.
■ Do not use the unit in areas where there is risk of explosions.
■ Do not use the unit in areas with significant temperature variations, exposure to condensation or ice.
■ The manufacturer is not responsible for any damages caused by inappropriate installation,
not maintaining the proper environmental conditions and using the unit contrary to its
assignment.
■ If in the case of a unit malfunction there is a risk of a serious threat to the safety of people or
property additional, independent systems and solutions to prevent such a threat must be used.
■ The unit uses dangerous voltage that can cause a lethal accident. The unit must be switched off
and disconnected from the power supply prior to starting installation of troubleshooting (in the
case of malfunction).
■ Do not attempt to disassemble, repair or modify the unit yourself. The unit has no user serviceable parts.
■ Defective units must be disconnected and submitted for repairs at an authorized service center.
Specifications
General
Display
Displayed Values
Transmission Parameters
Input Signal | Supply
Standard
Voltage
Output Signal | Supply
Standard
Voltage
Passive current output*
Performance
Accuracy
Accuracy According to IEC 60770 - Limit Point Adjustment | Non-Linearity | Hysteresis | Repeatability
Temperatures
Operating Temperatures
Materials | Wetted
Housing
Model Selection
ITC 450 — Industrial Level Controller
Part Number Input
ITC 450-1121
4-20 mA
ITC 450-1129 4-20 mA
24-0352 © Icon Process Controls Ltd.
LED | 4 x 20mm High | Adjustable Color & Brightness
-999 - 9999
1200...115200 bit/s, 8N1 / 8N2
Universal Input: 0 | 4-20mA | 0-10V | 0-150mV RTD | pH
85 - 260V AC/DC | 16 - 35V AC, 19 - 50V DC*
ITC450: 4 x Relays (5A) | 2 x Relays (5A) + 4-20mA • ITC350: 1 x Relay (5A) + 4-20mA
24VDC
4-20mA | (Operating Range Max. 2.8 - 24mA)
0.1% @ 25°C One Digit
-40 - 158°F | -40 - 70°C
NORYL
Output Part Number
ITC 350-1119
4 Relay
4-20 mA + 2 Relay ITC 350-1120
ITC 350 — Industrial Level Controller
Input
4-20 mA
4-20 mA 4-20 mA + 1x (5A) Relay
*Contact Factory for different options
Output
-
PC
