- Page 1 SICOM3024GS Industrial Ethernet Switch Hardware Installation Manual Publication Date:Sep. 2016 Version: V1.0 No.: 112020161...
- Page 2 All rights reserved. No part of this documentation may be excerpted, reproduced, translated, annotated or duplicated, in any form or by any means without the prior written permission of KYLAND Corporation. Copyright © 2018 Kyland Technology Co., Ltd.
- Page 3 Before using the device, read this manual carefully for personal and equipment safety. Please keep the manual for further reference. Kyland is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland representative: Water gets into the equipment. Equipment damage or shell damage.
-
Page 5: Table Of Contents
Contents 1 Product Overview ......................1 2 Structure and Interface ...................... 2 2.1 Front Panel ......................... 2 2.2 Rear Panel ........................3 3 Switch Installation ......................4 3.1 Dimension Drawing ..................... 4 3.2 Mounting Modes and Steps ..................5 4 Cable Connection ......................8 4.1 10/100/1000Base-T(X) Ethernet port ................ -
Page 6: Product Overview
Product Overview 1 Product Overview SICOM3024GS includes a series of managed industrial Ethernet switches tailored for high-power PoE applications, is suitable for rugged environment, such as video surveillance, security systems. SICOM3024GS has the characteristics of high bandwidth, multi-port, high power PoE, high-performance video transmission capacity etc. It can be widely used in petroleum and petrochemical, rail transit industry, factory automation, power and other industries. -
Page 7: Structure And Interface
Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure switch performance. 2.1 Front Panel Figure 1 Front Panel Table 2 Description of Front Panel Identifier Description Console Console port... -
Page 8: Rear Panel
Structure and Interface 2.2 Rear Panel Figure 2 Rear Panel Table 3 Description of Rear Panel Description Running LED Alarm LED Power 1 LED Power 2 LED 24*PoE LED 24* 10/100/1000Base-T(X) Ethernet PoE port 4*10G Base-X SFP+，1000Base-X SFP port Alarm terminal block Power terminal block (10) Grouding screw... -
Page 9: Switch Installation
Switch Installation 3 Switch Installation 3.1 Dimension Drawing Figure 3 Dimension Drawing (unit: mm) Caution: As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running. -
Page 10: Mounting Modes And Steps
Switch Installation 3.2 Mounting Modes and Steps The series switches support rack mounting by front/rear panel. The following uses mounting by front panel as an example to describe mounting steps. The steps for mounting by rear panel are similar to those for mounting by front panel. Before installation, make sure that the following requirements are met. - Page 11 Switch Installation use. As shown in the following figure, use three screws to secure two mounting brackets to the switch respectively. Figure 5 Installing Mounting Brackets Mounting Step 1: Select the mounting position for the device and guarantee adequate space and heat dissipation for it (dimensions: 440mm×44mm×355.7mm).
- Page 12 Switch Installation Step 2: Remove the switch from the rack posts. Then unscrew the mounting brackets to complete dismounting.
-
Page 13: Cable Connection
Cable Connection 4 Cable Connection 4.1 10/100/1000Base-T(X) Ethernet port 4.1.1 Functions Data Transmission 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M, 100M, or 1000M state, full or half duplex mode. - Page 14 Cable Connection Figure 7 RJ45 Port Table 1 Pin Definitions of 10/100/1000Base-T(X) RJ45 Port MDI-X Transmit/Receive Data (TRD1+) Transmit/Receive Data (TRD0+) Transmit/Receive Data (TRD1-) Transmit/Receive Data (TRD0-) Transmit/Receive Data (TRD0+) Transmit/Receive Data (TRD1+) Transmit/Receive Data (TRD3+) Transmit/Receive Data (TRD2+) Transmit/Receive Data (TRD3-) Transmit/Receive Data (TRD2-) Transmit/Receive Data (TRD0-) Transmit/Receive Data (TRD1-)
-
Page 15: 1000Base-X, 10/100/1000Base-T(X) Sfp Slot
Cable Connection 8-brown. 4.2 1000Base-X, 10/100/1000Base-T(X) SFP Slot 1000Base-X, 10/100/1000Base-T(X) SFP slot (Gigabit SFP slot): You can enable data transmission only after inserting an SFP optical/electrical module into the slot and connecting cable properly. The following table lists the Gigabit SFP optical/electrical modules (optional) supported by the series switches. - Page 16 Cable Connection Figure 10 Cable Connection of Gigabit SFP Optical Module How to Connect the SFP Optical Module Insert the SFP optical module into the SFP slot in the switch, and then plug the optical fiber into the TX port and RX port of the SFP module. Figure 11 Connecting the Gigabit SFP Optical Module How to Determine the RX Port and TX Port of Gigabit SFP Optical Module 1.
-
Page 17: Gigabit Sfp Electrical Module
Cable Connection 4.2.2 Gigabit SFP Electrical Module Figure 12 Gigabit SFP Electrical Module How to Connect the Gigabit SFP Electrical Module Insert the SFP electrical module into the SFP slot in the switch, and then plug the RJ45 connector of the twisted pair into the SFP module. Figure 13 Connecting the Gigabit SFP Electrical Module 4.3 10GBase-X SFP+ port 10GBase-X SFP+ slot (10GBase-X SFP+ slot) requires an SFP+ optical module to... -
Page 18: Console Port
Cable Connection 4.4 Console Port There is a Console port on the front panel of the switch, as shown in Figure 14. Connect the 9-pin serial port of a PC to the console port of the switch with a DB9-RJ45 console cable. You can configure, maintain, and manage the switch by running Hyper Terminal in the Windows OS of a computer. -
Page 19: Grounding
Cable Connection 4.5 Grounding Grounding protects the device from lightning and interference. Therefore, you must ground the device properly. You need to ground the device before it is powered on and disconnect the grounding cable after the device is powered off. There is a grounding screw(see Figure 2) on the top panel of the device. -
Page 20: Alarm Terminal Block
Cable Connection PWR1: + PWR1: L PWR1: - PWR1: N PWR2: + PWR2: L PWR2: - PWR2: N PGND PGND Caution: For single power supply, only pins 1, 2, and 3 (PWR1) of the terminal block can be connected. Do not use pins 4 and 5. -
Page 21: Leds
LEDs open. When an alarm occurs, the normally-open contacts are open and the normally-closed contacts are closed. The alarm is outputted through a 3-pin 5.08mm spacing terminal block, as shown in Figure 17. Figure 17 Alarm Terminal Block Electrical parameters of the relay: Max Switch Voltage: 250VAC/220VDC Max Switch Current: 2A Max Switch Power: 60W... - Page 22 LEDs Power 2 is not connected or operates abnormally. 10G working state (10GBase-X) SFP+ optical module 1000 working state (1000Base-X) or no Base-X connection ， SFP+ 1000M working state (1000Base-X) 1000Base-X SFP optical module 100M working state (100Base-FX) or no SFP port speed connection LEDs-...
- Page 23 LEDs working state No effective port connection Effective port connection and 10/100M working state (10/100Base-T(X)) 10/100Base-T(X) Ethernet port connection Ongoing network activities and 10/100M status LED (green) Blinking working state No effective port connection LED 1 and LED 2 indicate the status of the lower gigabit SFP slot, while LED 3 and LED 4 indicate the status of the upper gigabit SFP slot.
-
Page 24: Switch Access
Switch Access 6 Switch Access You can access the switch in any of the following ways: 6.1 Access through Console Port Step 1: Connect the console port of the switch to the 9-pin serial port of a PC with the delivered DB9-RJ45 console cable. - Page 25 Switch Access Figure 19 Selecting the Communication Port in Use Note: To confirm the communication port in use, right-click [My Computer] and click [Property]→ [Hardware]→[Device Manager]→[Port] to view the communication port. Step 5: Set port parameters (Bits per second: 9600, Data bits: 8, Parity: None, Stop bits: 1, and Flow control: None), as shown in Figure 20.
-
Page 26: Access Through Telnet
Step 2: Enter "telnet IP-address" in the Run dialog box, as shown in Figure 21. The default IP address of a Kyland switch is 192.168.0.2. Figure 21 Access through Telnet Step 3: Click OK. The Telnet CLI is displayed. Then you can enter commands (as shown in Table 10) to perform operations. - Page 27 Switch Access Step 2: Enter the IP address of the switch in the address box of the browser. The user login interface is displayed. You can log in to the Web UI by default user name "admin" and password "123". Note: ...
-
Page 28: Basic Features And Specifications
Basic Features and Specifications 7 Basic Features and Specifications Power Requirements Power Identifier Rated Voltage Range Maximum Voltage Range H3 (220AC) 220VAC 85-264VAC Power terminal 5-pin 7.62mm-spacing plug-in terminal block Rated Power Consumption No PoE：62W； Rated Power Consumption POE：430W Physical Characteristics Housing Metal, fanless Installation... - Page 29 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
