Mount the lens mount adapter

Various lenses can be used by changing the lens mount adapter.
Lens mount adapters are shipped adjusted for each camera in which the adapter
will be used. Do not mount it on any other camera.
When mounting the F-mount adapter
Protective
glass
(00512)
1 Turn OFF the camera and the AC adapter.
2 Loosen the lens mount fixing screw attached to the
camera.
The C-mount adapter can be removed by loosening
four positions.
3 Remove the lens mount attached to the camera.
• There is protective glass in place when the mount
adapter is removed but it's surface should not be
touched. If dirt adheres to it, the image quality may
be sacrificed
• The protective glass can be easily damaged.
If soiled with oil or such, please take to the retail out-
let for cleaning.
4 Mount the F-mount adapter and tighten the four
screws.
When installing, make sure that the metal fitting is in
the position indicated by the red circle.
25

Mount the lens mount adapter
