External Appearance and Names of Each Part
POWER LED
Camera's
LED Status power sta-
tus
Flashing white Power on
White Power on
Red Power on
Orange Power off
Flashing red Power off
Flashing orange
(1 Second inter- Power on
val)
Flashing orange
(0.5 Second Power on
interval)
Flashing blue Power on
Not lit Power off
Red and green
alternating
lights
• Thermal shutdown automatically shuts down the camera when the internal
temperature becomes extremely high.
• If a thermal shutdown occurs, turn off AC adapter or remove the battery, turn
off the power to thecamera, and then turn it on again to restart.
• The fail status means that one of failure detection, power supply voltage ab-
normality detection, sensor temperature rise detection, trigger signal abnor-
mality detection, or setting abnormality detection has occurred during camera
activation.
Operation
Camera is activated.
Camera starts up and is in normal status.
Fail (abnormal) state.
External power is being supplied and the camera is turned
off with the power switch.
The external power supply voltage is within the specifica-
tion range (13 to 32V) and in normal condition.
External power is being supplied and the camera is turned
off with the power switch.
The external power supply voltage is outside the specified
range (13 to 32V) and is abnormal.
From the moment the power is pressed until the power is
turned OFF.
Sleep state.
The status between the camera's power ON and the cam-
era's startup.
No external power supply.
Thermal shutdown occurs.
