Roger Access Control System
OSR80M-BLE Operating Manual
Product version: 1.0
Firmware version: 1.0.8.205 or newer
Document version: Rev.D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSR80M-BLE and is the answer not in the manual?

Questions and answers

Related Manuals for Roger OSR80M-BLE

Summary of Contents for Roger OSR80M-BLE

  • Page 1 Roger Access Control System OSR80M-BLE Operating Manual Product version: 1.0 Firmware version: 1.0.8.205 or newer Document version: Rev.D...

  • Page 2: Design And Application

    Android or IOS phone. Reader is equipped with two functional keys: Door Bell and Light which can be programmed for other function if necessary. The OSR80M-BLE can be used in the RACS 5 access control and building automation system using the additional MCI-3 interface. Because of its relatively small size, reader can be also used as locker/cabinet reader.
  • Page 3 OSR80M-BLE Operating Manual.doc 15.03.2024 Fig. 1 OSR supply from MC16 access controller Fig. 2 OSR supply from dedicated power supply unit OSDP bus The communication method with access controller is provided via the OSDP protocol on the RS485 bus. The device can be connected directly to access controllers supporting this bus. However, for the MC16 controller, it is additionally necessary to use the MCI-3 interface.

  • Page 4: Function Keys

    OSR80M-BLE Operating Manual.doc 15.03.2024 Function keys The terminal is equipped with two touch function keys and . Various functions can be assigned to these keys within high level configuration (VISO) e.g. door bell, Set T&A Mode, Register Guard Tour Event, Set Automation Node On, etc.

  • Page 5: Installation

    Bluetooth additionally verify if the parameter BLE activated is enabled. Install Roger Mobile Key (RMK) app on mobile device and configure the same parameters as in the terminal. Create key (authentication factor) in RMK defining its type and number, then create the same authentication factor in VISO software (fig.
  • Page 6 OSR80M-BLE Operating Manual.doc 15.03.2024 Yellow OSDP interface, line A Green OSDP interface, line B Fig. 5 Programming jumpers 6/15...
  • Page 7 OSR80M-BLE Operating Manual.doc 15.03.2024 Fig. 6 OSR80M-BLE installation 7/15...

  • Page 8: Operation Scenarios

    OSR80M-BLE Operating Manual.doc 15.03.2024 Note: OSR80M-BLE enclosure consists of front panel and back panel. New device is assembled with a standard back panel, but additional free of charge, extended back panel is included. This panel can be used when connection cable has to be hidden and no flush mounting box is available.

  • Page 9: Low Level Configuration (Rogervdm)

    OSR80M-BLE Operating Manual.doc 15.03.2024 Direct connection to the OSDP controller It is possible to make a direct connection of the OSR reader directly to the OSDP controller. An exemplary connection diagram is shown below. Fig. 8 Connecting the OSR reader directly to the OSDP controller.
  • Page 10 RMK which are acceptable for terminal. Range: [1]: REK, [2]: UCE, [3]: UCE + REK. Default value: [3]: UCE + REK. NFC authentication factor class Parameter defines acceptable type of keys (authentication factors) created in Roger Mobile Key app for NFC communication. UCE means 10/15...
  • Page 11 OSR80M-BLE Operating Manual.doc 15.03.2024 lower security and quicker identification while REK means higher security and slower identification. It is necessary to apply classes in RMK which are acceptable for terminal. Range: [1]: REK, [2]: UCE, [3]: UCE + REK. Default value: [2]: UCE.
  • Page 12 0-31 and 0-14 for sectors 32-39. Default value: 0. Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B, [2]: Roger. Default value: [0]: A. Parameter defines 6 bytes (12 HEX digits) key for accessing sector where PCN is stored.

  • Page 13: Manual Addressing

    OSR80M-BLE Operating Manual.doc 15.03.2024 for sectors 0-31 and 0-14 for sectors 32-39. Default value: 0. Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B. Default value: [0]: A. Programmable card number (PCN) settings for Mifare Desfire Sector type Parameter defines sector type with programmable number (PCN).

  • Page 14: Memory Reset

    The purpose of high level configuration is to define logical functioning of the terminal which communicates with the MC16 access controller, and it depends on applied scenario of operation. The example of access control system configuration is given in AN006 application note which is available at www.roger.pl. 5. F IRMWARE UPDATE The firmware of device can be changed to newer or older version.

  • Page 15: Ordering Information

    Outdoor MIFARE DESFire/Plus/NFC/Bluetooth access terminal; OSDP v2.2; 2 function keys MCI-3 The interface enables the connection of a reader that uses OSDP protocol to the MC16 series access controller (RACS 5 system). Portable USB-RS485 communication interface dedicated to ROGER access RUD-1 control devices 8. P RODUCT HISTORY Table 7.
