- Page 1 Roger Access Control System OSR88M-IO Operating Manual Product version: 1.0 Firmware version: 1.0.8.205 or newer Document version: Rev.B...
-
Page 2: Design And Application
1. D ESIGN AND APPLICATION The OSR88M-IO is an identification terminal dedicated to work with an access controller that supports the OSDP v2.2 protocol. The terminal is equipped with colour graphic display, sensor type keypad, 4 function keys and MIFARE Ultralight/Classic/DESFire/Plus/ reader. Users can identify at the terminal with PINs, MIFARE cards or mobile devices equipped with NFC (Near Field Communication) and BLE (Bluetooth Low Energy) interfaces. - Page 3 OSR88M-IO Operating Manual.doc 20/10/2023 Fig. 1 OSR supply from MC16 access controller Fig. 2 OSR supply from dedicated power supply unit OSDP bus The communication method with access controller is provided via the OSDP protocol on the RS485 bus. The device can be connected directly to access controllers supporting this bus. However, for the MC16 controller, it is additionally necessary to use the MCI-3-LCD interface.
-
Page 4: Function Keys
OSR88M-IO Operating Manual.doc 20/10/2023 Display The terminal is equipped with colour display (4 lines, 16 characters each). The display can be configured in regard of background and font colours within low level configuration (RogerVDM) and in regard of displayed information within high level configuration by means of Display command in VISO software navigation tree which is explained in AN011 application note. -
Page 5: Tamper Detector
OSR88M-IO Operating Manual.doc 20/10/2023 LED SYSTEM Orange LED indicates card reading and can signal other system functions including device malfunction. Note: Synchronic pulsing of LED indicators signifies lost communication with MC16 controller. Buzzer The terminal is equipped with buzzer which is used to signal integral functions and it can be additionally programmed with other available functions within high level configuration (VISO). -
Page 6: Installation
Bluetooth additionally verify if the parameter BLE activated is enabled. Install Roger Mobile Key (RMK) app on mobile device and configure the same parameters as in the terminal. Create key (authentication factor) in RMK defining its type and number, then create the same authentication factor in VISO software (fig. - Page 7 OSR88M-IO Operating Manual.doc 20/10/2023 Name Description OUT2 OUT2 output line OUT1 OUT1 output line IN3 input line IN2 input line IN1 input line REL1 relay normally opened contact REL1 relay normally closed contact REL1 relay common contact OSDP bus, line B...
- Page 8 OSR88M-IO Operating Manual.doc 20/10/2023 Fig. 5 OSR88M-IO installation 8/18...
-
Page 9: Operation Scenarios
OSR88M-IO Operating Manual.doc 20/10/2023 Fig. 6 Internal side of the front panel Installation guidelines • The terminal should be mounted on a vertical structure (wall) away from sources of heat and moisture. • Front panel should be attached in such way as the tamper detector (fig. 6) would firmly press the back panel. - Page 10 OSR88M-IO Operating Manual.doc 20/10/2023 Fig. 7 Typical connection diagram for the terminal and MC16 access controller via the MCI-3-LCD interface. Direct connection to the OSDP controller It is possible to make a direct connection of the OSR reader directly to the OSDP controller. An exemplary connection diagram is shown below.
-
Page 11: Low Level Configuration (Rogervdm)
OSR88M-IO Operating Manual.doc 20/10/2023 Low level configuration (RogerVDM) Fig. 9 Connection to RUD-1 interface. Programming procedure with RogerVDM software: 1. Connect the device to RUD-1 interface (fig. 9) and connect the RUD-1 to computer’s USB port. 2. Remove jumper from MEM contacts (fig. 6) if it is placed there. - Page 12 Parameter defines acceptable type of keys (authentication factors) NFC authentication factor class created in Roger Mobile Key app for NFC communication. UCE means lower security and quicker identification while REK means higher security and slower identification. It is necessary to apply classes in RMK which are acceptable for terminal.
- Page 13 OSR88M-IO Operating Manual.doc 20/10/2023 No, [1]: Yes. Default value: [1]: Yes. BLE session timeout [s] Parameter defines maximal time for establishing connection between mobile device and terminal in Bluetooth technology. When timeout elapses the session is interrupted by terminal so mobile device could attempt to establish connection again.
- Page 14 0-31 and 0-14 for sectors 32-39. Default value: 0. Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B, [2]: Roger. Default value: [0]: A. Parameter defines 6 bytes (12 HEX digits) key for accessing sector where PCN is stored.
-
Page 15: Manual Addressing
OSR88M-IO Operating Manual.doc 20/10/2023 Application ID (AID) Parameter defines application ID number (AID) which indicates sector where PCN number is stored. Range: 0-9999. Default value: 5156. Block ID Parameter defines block number where PCN is stored. Range: 0-2 to for sectors 0-31 and 0-14 for sectors 32-39. Default value: 0. -
Page 16: Memory Reset
The purpose of high level configuration is to define logical functioning of the terminal which communicates with the MC16 access controller and it depends on applied scenario of operation. The example of access control system configuration is given in AN006 application note which is available at www.roger.pl. 5. F IRMWARE UPDATE The firmware of device can be changed to newer or older version. -
Page 17: Specification
QUADRUS series design MCI-3-LCD The interface enables the connection of the OSR88M-IO with OSDP v2 communication protocol to the MC16 series controllers (RACS 5 system); 12 VDC power supply MCX8-BRD I/O expander; 8 supervised inputs; 8 relay outputs 1.5 A/30 V; 13.8 VDC supply input. - Page 18 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
