ASSEMBLY

To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480.
Make sure that the power cord is unplugged. Assembly requires two persons. Set the treadmill in a cleared
area and remove all packing materials. Do not dispose of the packing materials until assembly is completed.
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal
condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off
the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex keys
adjustable wrench
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number after the parentheses
is the quantity needed for assembly. Note: If a part is not in the parts bag, check to see if it is preattached to
one of the parts to be assembled. Extra hardware may be included. To avoid damaging plastic parts, do
not use power tools for assembly.
M8 Star
Washer (10)–4
Washer (8)–4
Bolt Spacer (79)–4
1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (48) so that the treadmill is more stable;
do not fully fold the Frame yet.
Cut the tie securing the Upright Wire (77) to the
Base (85). Locate a tie in the indicated hole in
the Base, and use the tie to pull the Upright Wire
out of the hole.
Attach a Base Pad (81) to the Base (85) in the
location shown with a Base Pad Spacer (71)
and an M4 x 25mm Screw (2). Then, attach an-
other Base Pad (81) with only an M4 x 25mm
Screw (2).
and your own Phillips screwdriver
, and scissors
M10 Star
M10 Nut
(33)–2
M4 x 18mm
Latch Screw (101)–2
M10 x 96mm Bolt (5)–4
.
#8 x 1/2" Screw
Base Pad Spacer
(71)–2
M4 x 19mm
Screw (1)–6
1
Hole
48
71
81
2
6
,
M4 x 25mm
(3)–1
Screw (2)–4
M8 x 25mm
Bolt (6)–4
M10 x 50mm Bolt (27)–2
85
77
81
2
