ICON NordicTrack COMMERCIAL 2950 User Manual
  1. Manuals
  2. Brands
  3. ICON Manuals
  4. Treadmill
  5. NordicTrack COMMERCIAL 2950
  6. User manual

ICON NordicTrack COMMERCIAL 2950 User Manual

Hide thumbs Also See for NordicTrack COMMERCIAL 2950:
Table of Contents

Advertisement

Quick Links

nordictrack.com
Model No. NTL19119.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.nordictrack.com
CUSTOMER CARE
For service at any time, go to
nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NordicTrack COMMERCIAL 2950 and is the answer not in the manual?

Questions and answers

Matt
January 19, 2025

I have to move the treadmill to another house. How can I disassemble it for transport

0
1 comments:
Mr. Anderson
May 14, 2025

To disassemble the NordicTrack COMMERCIAL 2950 treadmill for transport:

1. Unplug the power cord and remove the safety key.
2. Ensure the treadmill is set to zero incline before folding.
3. Fold the treadmill: Hold the frame and one handrail, place a foot against a wheel, bend your legs, and lift the frame until the storage latch locks.
4. Move the treadmill by tipping it back onto the wheels. Do not pull on plastic parts.
5. Disassembly tools needed: Hex key (included), adjustable wrench, and Phillips screwdriver. Do not use power tools.
6. Remove the tie securing the Upright Wire (83) to the front of the treadmill.
7. Place all parts in a clear area and keep packing materials until assembly is complete.

Note: The treadmill is heavy (you must be able to lift 45 lbs/20 kg), and moving or disassembling it may require two people.

This answer is automatically generated

0

Related Manuals for ICON NordicTrack COMMERCIAL 2950

Summary of Contents for ICON NordicTrack COMMERCIAL 2950

  • Page 1 nordictrack.com Model No. NTL19119.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com CUSTOMER CARE For service at any time, go to nordictrackservice.com.

  • Page 2: Table Of Contents

    Note: The decals may not be shown at actual size. NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Wi-Fi is a registered trademark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi Alliance. The Bluetooth ®...

  • Page 3: Important Precautions

    To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. Always stand on the foot rails when starting frame securely in the storage position. Do or stopping the walking belt. Always hold the not operate the treadmill while it is folded. handrails while using the treadmill. 27. Do not change the incline of the treadmill by 20.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK COMMERCIAL 2950 treadmill. manual. To help us assist you, please note the product ® The COMMERCIAL 2950 treadmill offers an impres- model number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 9 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (83) to the front of the Base (93). Next, identify the Right Upright (84). Have a second person hold the Right Upright near the Base (93).
  • Page 10 4. Hold the Right Upright (84) against the Base (93). Make sure not to pinch the Upright Wire (83). Attach the Right Upright (84) with two 3/8" x 2 3/4" Screws (23), two 3/8" x 1 1/4" Screws (20), and four 3/8" Star Washers (25) as shown; do not fully tighten the Screws yet.
  • Page 11 6. Carefully slide the Upright Crossbar (76) between the Right and Left Uprights (84, 91). Attach the Upright Crossbar with four 5/16" x 3/4" Screws (1); start all four Screws, and then tighten them. 7. Attach the Tray (79) to the Upright Crossbar (76) with four #8 x 3/4"...
  • Page 12 8. Attach the two Handrails (74) to the Right and Left Uprights (84, 91) with two 5/16" x 2" Screws (2) and two 5/16" Star Washers (8); do not fully tighten the Screws yet. Be careful not to pinch the Upright Wire (83) on the right side. Position the Upright Wire in the notch (F) as shown.
  • Page 13 10. IMPORTANT: To avoid damaging the Pulse Crossbar (80), do not use power tools, and do not overtighten the #10 x 3/4" Screws (6) or the 5/16" x 2" Screws (2). Orient the Pulse Crossbar (80) as shown. Attach the Pulse Crossbar to the Handrails (74) with two 5/16"...
  • Page 14 12. Attach the console assembly (H) to the Handrails (74) with four 5/16" x 2" Screws (2) and four 5/16" Star Washers (8); start all four Screws, and then tighten them. Be careful not to pinch the wires (J). Insert the wires (J) into the top of the Right Upright (84).
  • Page 15 14. Start eight #8 x 3/4" Truss Head Screws (24) into the Pulse Crossbar (80), and then tighten them; do not overtighten the Truss Head Screws. 15. Set the Left Handrail Top Cover (73) on the left Handrail (74). Start four #8 x 3/4" Truss Head Screws (24) into the Left Handrail Bottom Cover (75), the left Handrail, and the Left Handrail Top Cover.
  • Page 16 16. Raise the Frame (52) to the upright position. Have a second person hold the Frame until step 18 is completed. Remove the two 5/16" x 1 1/4" Screws (16) from the Latch Crossbar (109). Orient the Latch Crossbar (109) as shown. Make sure that the “This side toward belt”...
  • Page 17 18. Remove the 5/16" Nut (9) and the 5/16" x 2 1/4" Bolt (4) from the bracket on the Frame (52). Align the upper end of the Storage Latch (56) with the bracket on the Frame (52), and insert the 5/16" x 2 1/4" Bolt (4) through the bracket and the Storage Latch.

  • Page 18: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Store the heart rate monitor in a warm, dry place. Do not store the heart rate monitor in a plastic bag or If the heart rate monitor looks like the one shown other container that may trap moisture.

  • Page 19: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
  • Page 20 CONSOLE DIAGRAM FEATURES OF THE CONSOLE In addition, the console features a selection of work- outs. Each workout automatically controls the speed The advanced treadmill console offers a selection of and incline of the treadmill as it guides you through an features designed to make your workouts more effec- effective exercise session.
  • Page 21 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 22 HOW TO SET UP THE CONSOLE 5. Check for firmware updates. Before using the treadmill for the first time, set up the First, touch your name in the upper-left corner and console. touch the Settings button. Next, select the main- tenance section.
  • Page 23 HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the Incline increase and decrease buttons or one of the See HOW TO TURN ON THE POWER on numbered incline buttons.
  • Page 24 • Your pace To measure your heart rate, stand on the foot rails and hold the contacts with your palms for • The speed of the walking belt approximately ten seconds; avoid moving your hands. When your pulse is detected, your heart •...
  • Page 25 HOW TO USE A MAP WORKOUT 5. Monitor your progress with the display modes. Note: To use a map workout, the console must be con- See step 5 on page 23. nected to a wireless network (see HOW TO USE THE WIRELESS NETWORK MODE on page 28).
  • Page 26 Cancel button to exit the login screen. 5. Select a distance or time workout that you have previously added to your schedule on iFit.com. Touch the calendar icon to download a distance or time workout from your schedule. Note: Before workouts will download, you must add them to your schedule on iFit.com.
  • Page 27 6. Start the workout. 3. Customize settings. See step 4 on page 25. Note: During a distance or To customize settings, touch the desired category, time workout, the display will not show a map. and then touch the toggle button at the side of the category name.
  • Page 28 HOW TO USE THE MAINTENANCE SECTION IMPORTANT: Keep pets, feet, and other objects away from the treadmill while the incline sys- 1. Select the settings main menu. tem is calibrating. In an emergency, pull the key from the console to stop the incline calibration. See step 1 on page 27.
  • Page 29 An information box will ask if you want to connect HOW TO USE THE SOUND SYSTEM WITH A to the wireless network. Touch the Connect button BLUETOOTH DEVICE to connect to the network or touch the Cancel but- ton to return to the list of networks. If the network 1.
  • Page 30 HOW TO ADJUST THE ANGLE OF THE CONSOLE HOW TO ADJUST THE CUSHIONS To adjust the angle of the console, hold both sides of The treadmill features cushions that reduce the impact the console and tilt it to the desired position. as you walk or run on the treadmill.

  • Page 31: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 32: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for fi...
  • Page 33 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the specifi cations described on page 19. a. If the walking belt is off-center, fi rst remove the key and UNPLUG THE POWER CORD.
  • Page 34 SYMPTOM: The displays of the console do not SYMPTOM: The console does not stay in place function properly a. If the console does not stay in the desired position a. If the console does not boot up properly, or if the because it is too loose, use a hex key to slightly console freezes and does not respond, reset the tighten the console in the indicated location on both...

  • Page 35: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 36 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 37 NOTES...

  • Page 38: Part List

    PART LIST Model No. NTL19119.0 R1118A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Drive Roller/Pulley 5/16" x 2" Screw Frame 5/16" x 1 3/4" Bolt 5/16" x 2 1/4" Bolt Drive Motor #8 x 3/4" Screw Motor Belt #10 x 3/4"...
  • Page 39 Key No. Qty. Description Key No. Qty. Description Right Tray 1/4" x 5/8" Screw Hood Accent Adjustment Handle Hood Grill Cushion Bushing Key/Clip Cushion Rod Bracket Console Frame Cap Cushion Wheel Stop Console Frame M10 Spring Washer Cable Tie Cushion Wheel Cushion Rod 3/8"...

  • Page 40: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL19119.0 R1118A...
  • Page 41 EXPLODED DRAWING B Model No. NTL19119.0 R1118A 114 115...
  • Page 42 EXPLODED DRAWING C Model No. NTL19119.0 R1118A...
  • Page 43 EXPLODED DRAWING D Model No. NTL19119.0 R1118A...

  • Page 44: Ordering Replacement Parts
