Model No. NETL19818.1
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
iconeurope.com
Advertisement
Table of Contents
Related Manuals for ICON NordicTrack C1650
Summary of Contents for ICON NordicTrack C1650
- Page 1 Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT WF5 9TT UNITED KINGDOM AUSTRALIA Call: 1800 993 770 E-mail: australiacc@iconfitness.com...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at actual size. NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Google Maps is a trademark of Google LLC. The BLUETOOTH ®... -
Page 3: Important Precautions
To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 21. The treadmill is capable of high speeds. frame securely in the storage position. Do Adjust the speed in small increments to not operate the treadmill while it is folded. avoid sudden jumps in speed. 26. Do not change the incline of the treadmill by 22.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK ® manual. To help us assist you, note the product model C 1650 treadmill. The C 1650 treadmill provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 7: Assembly
ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •... - Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
- Page 9 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (25) with two 3/8" x 2 1/4" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
- Page 10 6. Identify the left handrail assembly (E). Attach the left handrail assembly to the Left Upright (89) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); do not fully tighten the Screws yet. Then, remove and discard the indicated screw (F).
- Page 11 8. Tighten four #8 x 3/4" Screws (2) into the left and right handrail assemblies (E, G) and into the Left and Right Uprights (89, 90). 9. Set the Console Base (64) face down on a soft surface to avoid scratching the Console Base. If there are ties (H) securing the Pulse Crossbar (93) to the Console Base, remove the ties.
- Page 12 10. Identify the Right and Left Trays (27, 36). Attach the Trays (27, 36) to the Console Base (64) with eight #8 x 1/2" Screws (1); do not overtighten the Screws. Hold the Console Frame (18) near the Console Base (64) and connect the Console Ground Wires (58) to the ground wires (J) in the Console Base.
- Page 13 12. With the help of a second person, hold the con- sole assembly (K) near the Handrails (86) (only one side is shown). Connect the ground wire (J) from the console assembly (K) to the Console Ground Wire (58) on the Pulse Crossbar (93). Next, insert the Upright Wire (81) through the two indicated looped ties (L) on the console assembly (K).
- Page 14 14. Attach the Pulse Crossbar (93) to the console assembly (K) with four #8 x 1/2" Screws (1); start all four Screws, and then tighten them. Then, firmly tighten the four 5/16" x 3/4" Screws (4). 15. Carefully slide the Upright Crossbar (12) between the Left and Right Uprights (89, 90).
- Page 15 17. Note: If the treadmill is assembled on a smooth surface, it may roll forward in this step. Remove the two 5/16" x 3/4" Screws (4) from the Latch Crossbar (41). Raise the Frame (56) to the upright position. Have a second person hold the Frame until step 19 is completed.
- Page 16 19. Remove the 5/16" Nut (34) and the 5/16" x 2 1/4" Bolt (3) from the bracket on the Latch Crossbar (41). Align the upper end of the Storage Latch (53) with the bracket on the Latch Crossbar (41), and insert the 5/16" x 2 1/4" Bolt (3) through the bracket and the Storage Latch.
- Page 17 21. Press the two tabs on the Tablet Holder (98) into the slots (R) in the console assembly (K). Attach the Tablet Holder (98) with four #8 x 5/8" Machine Screws (38). Note: Start the top two Start First Machine Screws fi rst, and then start the bot- tom two Machine Screws.
-
Page 18: How To Use The Treadmill
HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill. - Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE compatible heart rate monitor. See page 28 for infor- mation about purchasing an optional chest heart The advanced treadmill console offers a selection of rate monitor. features designed to make your workouts more effec- tive and enjoyable.
- Page 20 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
- Page 21 HOW TO SET UP THE CONSOLE 6. Calibrate the incline system. Before using the treadmill for the first time, set up the First, touch the profile button. Next, select the set- console. tings main menu. Then, select the maintenance section, touch the Calibrate Incline button, and then 1.
- Page 22 3. Start the walking belt and adjust the speed. • Your vertical loss Touch the Manual Start button in the upper-right • The elapsed time corner of the screen or press the Start button on the console to start the walking belt. The walk- •...
- Page 23 Before using HOW TO USE A MAP WORKOUT the handgrip heart rate mon- 1. Insert the key into the console. itor, remove the sheets of See HOW TO TURN ON THE POWER on plastic from the page 20. metal contacts. In addition, 2.
- Page 24 5. Monitor your progress with the display modes. 4. Save your workout. See step 5 on page 22. Touch the Save New Workout button in the lower- left corner of the screen. If desired, change the title 6. Measure your heart rate if desired. of the workout or add a description, and then press the >...
- Page 25 5. Select a distance or time workout that you have main menu. previously added to your schedule on iFit.com. 2. Select the workout section. Touch the calendar icon to download a distance or time workout from your schedule. In the settings main menu, scroll to the Workout section.
- Page 26 HOW TO USE THE EQUIPMENT SETTINGS Touch the Update button to check for firmware SECTION updates using your wireless network. The update will begin automatically. 1. Select the settings main menu. To avoid damaging the treadmill, do not turn off See step 1 on page 25.
- Page 27 HOW TO USE THE WIRELESS NETWORK MODE When the console is connected to your wireless network, a checkmark will appear next to the wire- The console features a wireless network mode that less network name. Then, touch the back button on allows you to set up a wireless network connection.
- Page 28 HOW TO CONNECT AN HDMI CABLE HOW TO USE THE TABLET HOLDER To show your console screen on a TV or monitor, plug IMPORTANT: The tablet holder is designed for use an HDMI cable (not included) into the port on the con- with most full-size tablets.
-
Page 29: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left. -
Page 30: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal per- a. Check the power switch (see drawing c at the left). formance and to reduce wear. Inspect and properly If the switch has tripped, wait for five minutes and tighten all parts each time the treadmill is used. - Page 31 Next, locate the Reed Switch (104) and the Magnet c. Your treadmill features a walking belt coated with (102) on the left side of the Pulley (49). Turn the high-performance lubricant. IMPORTANT: Never Pulley until the Magnet is aligned with the Reed apply silicone spray or other substances to Switch.
- Page 32 SYMPTOM: The walking belt slips when walked on SYMPTOM: The treadmill will not connect to the wireless network a. First, remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. Make sure that the wireless settings on the console screws clockwise, 1/4 of a turn.
-
Page 33: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 34: Part List
PART LIST Model No. NETL19818.1 R0418A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw 9/32" Plastic Bushing #8 x 3/4" Screw 3/8" Plastic Bushing 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 3/4" Screw Drive Motor #10 Star Washer Motor Belt 5/16"... - Page 35 Key No. Qty. Description Key No. Qty. Description 3/8" Washer Filter Magnet #8 x 1/2" Machine Screw Clip #8 Nut Reed Switch Motor Isolator Motor Bushing – User’s Manual Note: Specifi cations are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
-
Page 36: Exploded Drawing
EXPLODED DRAWING A Model No. NETL19818.1 R0418A... - Page 37 EXPLODED DRAWING B Model No. NETL19818.1 R0418A...
- Page 38 EXPLODED DRAWING C Model No. NETL19818.1 R0418A...
- Page 39 EXPLODED DRAWING D Model No. NETL19818.1 R0418A...
-
Page 40: Ordering Replacement Parts
European standards of environmental protection. If you require more information about safe and correct disposal methods, please contact your local city office or the establishment where you purchased this product. Part No. 401072 R0418A Printed in China © 2018 ICON Health & Fitness, Inc.
