Summary of Contents for Amos AEC 380
- Page 1 AEC 380 Embedding Center Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 2 Foreword Thank you for purchasing our AEC380 Embedding Center. This Operation Manual presents the functions, operation methods, and safety considerations for the Embedding Center. Please read this manual carefully before use to better understand its performance and make full use of its functions. If you have any questions, contact us, and we will provide satisfactory service at any time.
-
Page 3: Table Of Contents
Contents 1、Safety Notes.................................1 1.1 Safety Matters...............................1 1.2 Conditions of Installation .............................1 1.3 Delivery inspection...............................2 2、Scope of Application & Performance Characteristics...................2 2.1 Scope of Application ............................2 2.2 Performance Characteristics..........................2 3、Overview- Instrument Components.........................3 4、Technical Specification s ............................5 5、Installation Instructions.............................7 6、Operation Instructions............................10 6.1 Touch Screen Function &... -
Page 4: 1、Safety Notes
●No water droplets, steam, dust (including oily and floating dust). ●No corrosive, flammable, or explosive gases and liquids. ●Solid and non-vibrating surface. ●No interference from other electromagnetic signals. ●Operating ambient temperature from 5℃ to 40℃,relative humidity under 90% 。 AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---1... -
Page 5: Delivery Inspection
● Easy to learn user interface operating with smart color touch screen. ● Programmed timing automatic on / off . ● With a split modular design, AEC 380-PR Paraffin Reservoir can choose to connect with one or two sets of AEC 380-M embedding module according to embedding workload requirement. -
Page 6: 3、Overview- Instrument Components
According to different demand ,an AEC 380-PR paraffin reservoir can connect with 1 unit of AEC 380-M or 2 units of AEC 380-M. As an example of connecting one unit of the AEC 380-M, the main structure is shown below: AEC 380-M Embedding Module AEC 380-PR Paraffin Reservoir... - Page 7 17. Serial port Finger touch for wax flow 18. Foot switch socket Waste paraffin tray(right) 19. Power switch Embedding platform 20. Power socket Forceps holder 21. Fuse mounting hole Storage tray for Cassette Mould Ver: AMOSAEC380OP20240612 ---4 AEC 380 Embedding Center...
-
Page 8: 4、Technical Specification S
Fig 5 Technical parameters ： 1、 Capacity of Tissue Tray： 150pcs standard cassettes or 1 pc processor basket of AMOS with 100pcs standard cassettes） 2、 Capacity of Embedding Mold Tray：400pcs. 3、 Capacity of Storage Tray：300pcs standard cassettes or 2 pcs processor baskets of AMOS with 100pcs standard cassettes）... - Page 9 Fig 6 Technical parameters ： 1、 Capacity of Tissue Tray： 300pcs standard cassettes or 2 pcs processor basket of AMOS with 200 standard cassettes） 2、 Capacity of Embedding Mold Tray：800pcs 3、 Capacity of Storage Tray：600pcs standard cassettes or 4 pcs processor basket of AMOS with 100pcs standard cassettes）...
-
Page 10: 5、Installation Instructions
4.Wiring screwdriver *1 piece or cross screwdriver *1 piece. Installation steps: Put AEC 380-PR and AEC 380-M on the working table, showing back to installer firstly. I 1、 AEC 380-PR only connects with one embedding module, it can be put on the left or right according to user’s habit. - Page 11 Figure 9 below shows the connecting pipes used when the host is installed on the left side. locking nut connected Heating pipe with power cable and cable of sensor Fig 9 AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---8...
- Page 12 Connect the ends of attached data cable to paraffin reservoir and embedding module separately. 9、 Plug the two-power cable into power socket, and plug the foot pedal cable into the corresponding socket. The entire installation is now complete. AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---9...
-
Page 13: 6、Operation Instructions
Connect the power cable to the power supply and turn on the instrument. It will display the " Amos" logo first and automatically enter the control interface after 2 seconds. As an example, it introduces the control interface of combination 2. (The operation of combination 1 is similar to combination 2). - Page 14 After completing the settings, click the black arrow below to return to the main control interface, where you can see that the current time has been updated. week Hour Minutes Fig 14 AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---11...
- Page 15 Orange: Embedding reservoir Pink : Tissue tank Red： embedding platform and paraffin trimmer Blue :Tissue tray Blue :indicates forceps holder Blue :indicates forceps holder Green: Embedding mold tray Fig 15 Setting temperature Actual temperature AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---12...
- Page 16 "Enter" key to change the setting temperature. Click the return button to enter the main interface. Embedding module(left) Paraffin Reservior Embeddiing module(right) Return Temperature Display and Setting Switch Key Actual Temperature Setting Temperature Code for temperature control Fig 16 AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---13---...
-
Page 17: Operation Instruction S
6.2.6 Instructions for manual and foot pedal wax dispensing Preparation work before wax dispensing ■Wax melting takes a long time, so it's better to start working only AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---14... -
Page 18: Usage Of Forceps Holder
■ Turn on the cold spot switch (See Fig 3); it starts refrigerating and reaches the required operating temperature (usually -5°C to 0°C) within several minutes. This function is designed for users who do not use stainless steel embedding molds AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---15... -
Page 19: Usage Of Paraffin Trimmer
Finally, turn off the power switches and unplug the power cable from the socket. If the device has a timed heating setting, do not turn off the power switches. AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---16... -
Page 20: 7、Trouble Shooting
Damaged heate Replacing the heater area is not heated, multimeter. If there is an open the tissue circuit, it indicates that the heater is AEC 380 Embedding Center ---17--- Ver: AMOSAEC380OP20 240612... - Page 21 Wax t r a y the welding point leaking wax tray of the wax t r a y seepage If the above solution still cannot solve the problem, please contact the manufacturer's after-sales department Ver: AMOSAEC380OP20240612 AEC 380 Embedding Center ---18---...
-
Page 22: 8、Clearance & Maintenance
■Insert the fuse(1) into the fuse socket (2) as shown in the Fig19 Then insert the whole fuse socket into the socket (3). Before replacing the fuse, it is necessary to cut off the power supply and unplug the power cord. Fig 19 AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---19... -
Page 23: 9、 Diagram
9. Instrument Diagram AEC 380-M Embedding Module(platform) 24V- 24V+ 12V- 12V+ 24V- black 24V+ blue VAVEL VAVEL+ black blue black blue black blue black blue HEAT black PIPE-DC blue LED+ LED- black 12V- blue 12V+ AEC 380 Embedding Center Ver: AMOSAEC380OP20240612... - Page 24 AEC 380-PR Paraffin Reservoir 24V- 24V+ 12V- 12V+ PiPE Valve Button +24V- Heat black blue black blue black blue black blue AEC 380 Embedding Center Ver: AMOSAEC380OP20240612 ---21...
- Page 25 Standard configuration list Combination 1 : AEC 380-PR Paraffin Reservoir connects one piece of AEC 380-M Embedding Modul . Item Name Notes AEC 380-PR 1 unit AEC 380-M 1 unit Power Cord 2 pcs Serial cable 1 pc Connection board...
- Page 26 Combination 2 : AEC 380-PR Paraffin Reservoir connects two pieces of AEC 380-M Embedding Module. Notes Item Name AEC 380-PR 1 unit AEC 380-M 2 units Power Cord 3 pcs Serial cable 2 pcs Connection board 2 pcs Connection tube...
- Page 27 Published by: AMOS SCIENTIFIC PTY LTD Factory 24,632-642 Clayton Road,South Vic 3169,Melbourne, Australia Tel: +61-4-10190188 ABN 37 159 778 140 Website: www.amos-scientific.com...
