- Page 1 TEC 2800 （Version：AMOSTEC2800CCOP20150318） Cryo Console Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 2 Foreword Thank you for purchasing our TEC2800 Cryo console. Presented in this 《Operation Manual》 are the functions and operation method support for the Embedding Center and the matters needing attention concerning safety. Please carefully read this manual before use so that you can understand its performance better and make full use of the functions.
-
Page 3: Table Of Contents
Contents Safety Matters 1、 ..........................1 1.1、S ........................1 AFETY ATTENTIONS 1.2、C ...................... 1 ONDITIONS OF INSTALLATION 1.3、D ........................1 ELIVERY INSPECTION Characteristics & Application 2、 ....................2 Main Structure 3、 ..........................2 Technical Parameters 4、 ........................3 Operation Explanation 5、... -
Page 4: Safety Matters
1. Safety Matters ● Please read these explicit rules. Act in violation of them can affect normal operation of the equipment, cause damage to the equipment or result in danger. Use 220VAC± 10% at 50HZ or 110VAC± 10% at 60HZ The input power supply must have good earthing The equipment should be installed far away from flammable and explosive objects Don’t open the equipment without authorization to prevent high voltage... -
Page 5: Characteristics & Application
2.Characteristics & Application TEC2800 cryo console is support for Embedding Center. 3.Main Structure Display panel Freezing plate Power switch 4. Technical Parameters from +15℃ to -15℃ increments 1℃ Working temperature: Rated Power: 330W Supply voltage: AC 220V± 10% 50Hz or AC 110V± 10% 60Hz Fuse: 220V/8A or 110V/8A Noise: ≤50db Dimensions:... -
Page 6: Operation Explanation
5. Operation Explanation Please switch on the cryo console ten minutes before embedding. A. Connect the Cryo Console to the power supply and switch on the power supply B. And then press key TEMP.SET (the green light is on), while the screen will display the set temperature. - Page 7 Attention: --Don’t turn the machine on within five minutes after turning the table off (the effect of refrigeration is much better when turn the machine on after the temperature of the machine comes back to ambient --Don’t leave the paraffin piece on the table for long to prevent cracking --Enough space should be provided at the rear of the table heat dissipating area for quick heat dissipation.
-
Page 8: 6、Trouble Shooting
6、Trouble shooting Type Problem Possible causes Judge Method Corrective action Take out the fuse to check its internal Fuse broken resistance by multimeter, if the value is Replace a new one infinite, the fuse is broken Power cord plug poor Check the connection is good or not Plug in again No display on the... -
Page 9: 8、 Wiring Diagram Of Electrical Appliance
8、 Wiring Diagram of Electrical Appliance ---- 6 ---- TEC2800 Cryo Console AMOSTEC2800CCOP20150318... -
Page 10: Schematic Diagram Of Integrated Circuit
9、 Schematic Diagram of Integrated circuit 10、 Distribution Diagram Of Component ---- 7 ---- TEC2800 Cryo Console AMOSTEC2800CCOP20150318... - Page 11 Standard accessories list Accessory Name Notes Cryo console 1 set Power Cord Fuse 2pcs Operation Manual...
- Page 12 Published by: AMOS SCIENTIFIC PTY.LTD 1 Prestige Dr Clayton South VIC 3169 Melbourne， Australia Tel: +61-410190188FAX:+61-3-98081503 ABN 37 159 778 140 www.amos-scientific.com...
