- Page 1 TEC 2800 Version：（AMOSTEC2800ECOP20150318） Embedding Center(LCD) Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 2 Foreword Thank you for purchasing our TEC2800 Embedding Dispensing Console. Presented in this 《 Operation Manual 》 are the functions and operation method of the Embedding Center and the matters needing attention concerning safety. Please carefully read this manual before use so that you can understand its performance better and make full use of the functions.
-
Page 3: Table Of Contents
Contents Safety Notes 1、 ................................. 1 1.1 Safety Matters ..............................1 1.2 Installation Environment ............................. 1 1.3 Delivery Inspection .............................. 2 Characteristics & Scope of Application 2、 ..................... 2 2.1 Scope of Application............................2 2.2 Characteristics ..............................2 Safety Regulations 3、... -
Page 4: 1、Safety Notes
1、Safety Notes 1.1 Safety Matters Please read these explicit rules. Act in violation of them can affect normal operation of the equipment, cause damage to the equipment or result in danger. ● Use 220VAC± 10% at50HZ or 110VAC± 10% at60HZ ●... -
Page 5: Delivery Inspection
1.3Delivery inspection Although the product has already been inspected before leaving the factory, the following inspection is necessary at delivery because may be damaged and accessories get missing caused by careless handling during transportation. ●Open the packing boxes and check the contents to make sure that there exist the product, operation manual, certificate, packing list and accessories. -
Page 6: 4、Overview- Instrument Components
4、Overview- Instrument Components 1) Forceps holder 2) Embed table 3) Left tray 4) Right tray 5) Switch of flow out 6) Paraffin tank 7) Display panel 8) Flow Regulating knob 9) Peltier Cold Spot 10) Switch of cold spot 11) Power supply 12) Left Paraffin Drawer 13) Right Paraffin Drawer Fig （1）... -
Page 7: 6、Operation
6、Operation 6.1 Key board Function & Instruction Indicator lamp : Red lamp indicate heating ON Green indicate standby Fig2 Increase Value Heating/Standby Decrease Value Cycle Illuminating switch Timing Heat/Sleep set Illuminating switch off Temperature set 键 LCD on working state Temperatur Time（24hr）... -
Page 8: Operation Instruction
Function of Indicator Lamp The machine always on two states only, heating or standby. Red lamp indicate the machine is heating ON Green lamp indicate the machine is standby Function of Keyboard Heating/Standby ，machine is on heating or standby could be selected by this button. Cycle button. -
Page 9: Temperature Of Working Area Check And Set
○ you could choose the desired object hour, minute and date of week by pressing the cycle button ▲Attn：1.The machine has automatic memory of the time, date. If the time, date is set, even if the external power supply turn off, it doesn’t need to reset when the machine restart. - Page 10 Timing fix windows 。 Fig5 enter automatic time setting interface , * Press * Press to select the object: Hour, Minute , day of week, Heating, Standby. * Set the desired automatic time by and . * Press to quit . For example , it shows the automatic heating time is on Monday, time:18:03 on the Fig5 ▲Attention：When it appears icon of "moon"...
-
Page 11: Heating Mode And Sleep Mode Manually Set
Wednesday , AM8：00 at Automatic heating mode，Sleep at PM16:00； Thursday , AM8：00 at Automatic heating mode，Sleep at PM16:00； Friday , AM8：00 at Automatic heating mode，Sleep at PM16:00； Saturday, AM00：00 at Automatic heating mode，Sleep at any time； Sunday, AM00：00 at Automatic heating mode，Sleep at any time 6.2.4 Heating Mode and Sleep Mode Manually Set ■... -
Page 12: Lamp Open/Close And Lamp Intensity Adjustable
Fig （ 6） 6.2.7 Lamp open/close and Lamp intensity adjustable ■It has two modes : 1. The illuminate light of machine is default on the lightest. The machine will keep the lightest lamp by pressing to turn on or pressing to turn off. -
Page 13: 7、Trouble Shooting
7、Trouble Shooting Problem Issued Reason Judge method Corrective action Power supply not Connect the power Connect the power connect Take out the fuse to check its internal Fuse Open circuit resistance by multimeter, if the value is Replace a new one infinite, the fuse is broken LCD is unlit Check its output by multimeter DC gear. -
Page 14: 8、Clearance & Maintenance
Nozzle Set high temperature The lower temperature of Paraffin tube causes the paraffin not to Check each position’s temperature value electromagnetic melt in paraffin pipeline. valve Electromagnetism Valve no voice, Electromagnetism Valve Change the Check its wire resistance by multimeter, out of work, wires burns Electromagnetism if open circuit, it means the... -
Page 15: Maintenance
please removal to prevent the blocking wax. Left/right tray Cleaning ■Left/right tray is used part frequency, so please clean the impurity inside. Switch of flow out and adjustable knob Cleaning ■Please clean this parts always. Fig （ 9） Left/Right paraffin drawer Cleaning ■Please always to clean the residual wax inside. -
Page 16: 9、Instrument Diagram
9、Instrument Diagram Fig （11） ---13--- TEC2800 Embedding Center AMOSTEC2800ECOP20150318... - Page 17 Standard accessories list Accessory Name Notes Embedding Center 1 set Power Cord Fuse 2pcs Foot Switch Chrome coating with fixed mount (ZMNB-00-70). Adapter(ZMNB-00-83); Magnifier Connector (ZMNB-00-84)； Bolt :M4*12； Screw:M3*4* 1 pc Operation Manual...
- Page 18 Published by: AMOS SCIENTIFIC PTY.LTD 1 Prestige Dr Clayton South VIC 3169 Melbourne， Australia Tel: +61-410190188FAX:+61-3-98081503 ABN 37 159 778 140 www.amos-scientific.com...
