- Page 1 TEC 2500 Water bath-Slide drier Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 2 Fore Word Thank you for purchasing our TEC 2500 Water Bath-Slide Drier. Presented in this 《Operation Manual》 are the functions and operation methods of the TEC2500 Water Bath-Slide Dryer and the matters needing attention concerning safety. Please carefully read this manual before use so that you can understand its performance better and make full use of the functions.
-
Page 3: Table Of Contents
Contents 1. Safety Instruction ......................1 1.1 Safety Matters……………………………………………………………………1 1.2 Conditions of installation…………………………………………………………..1 1.3 Delivery Inspection………………………………………………… ..………….1 2. Performance Features & Range of Application ............... 1 3. Main structure ........................2 4. Technical Parameters ..................... 3 5. Operation ......................... 3 5.1Keypad Description &... -
Page 4: Safety Instruction
Although the product has already been inspected before leaving the factory, the following inspection is necessary at delivery because the product may be damaged and accessories get missing caused by careless handling during transportation. TEC 2500 Water Bath-Slide Drier ---1--- ---1---... -
Page 5: Performance Features & Range Of Application
The program control system makes operation easier and more reliable. TEC 2500 pathologic microtome section rinsing and drying apparatus can be widely used in such institutions as hospitals and scientific and research universities. -
Page 6: Technical Parameters
OVEN mode. TEC 2500 Water Bath-Slide Drier ---3--- ---3--- HESTION 201301040001EN TEC2500 Water Bath-Slide drier Ver:AMOSTEC2500OP20161115 its indicator light that means the machine is on WARMER drier mode. -
Page 7: Instruction
Now press to set ↑、↓the required temperature in the bath tank. 4. Press the key till the lamp Oven lights. Then press Test/set until the lamp set light. Now press to set ↑、↓the required temperature in the oven. TEC 2500 Water Bath-Slide Drier ---4--- ---4--- HESTION 201301040001EN... -
Page 8: Layout Of Components＆Electric Wiring Diagram
● Install fuse as figure(1) shown then put it into the installation part as figure(2)shown.At last put the whole installation into the receptacula as figure(3)shown. ● Before replacing the fuse must turn off the power switch and disconnect the power. Specification of fuse: 5A（220V）,8A(110V). TEC 2500 Water Bath-Slide Drier ---5--- ---5--- HESTION 201301040001EN... -
Page 9: Trouble Shooting
Take out the fuse to check its internal No heating Replace a new Fuse blow resistance by multimeter, if the value fuse is infinite, the fuse is broken TEC 2500 Water Bath-Slide Drier ---6--- ---6--- HESTION 201301040001EN TEC2500 Water Bath-Slide drier Ver:AMOSTEC2500OP20161115... -
Page 10: Layout Of Components In Pcb Circuit Board
SSR2 P3.2 DS18B20(B) EA/VP OVEN P0.5 DS18B20(O) ALE/P RESET PSEN BATH SSR1 P0.6 P3.1 DS18B20(W) 220V P0.7 IC1(DC) R23 R24 R26 R27 P3.0 P2.4 24c02 P2.5 TEC 2500 Water Bath-Slide Drier ---7--- ---7--- HESTION 201301040001EN TEC2500 Water Bath-Slide drier Ver:AMOSTEC2500OP20161115... -
Page 11: 0 . W I R I N G D I A G R A M
10. Wiring Diagram TEC 2500 Water Bath-Slide Drier ---8--- ---8--- HESTION 201301040001EN TEC2500 Water Bath-Slide drier Ver:AMOSTEC2500OP20161115... - Page 12 Standard Accessories List Accessory Name Notes Water bath-slide drier 1 unit Power Cord Fuse 2pcs Operation Manual...
- Page 13 Published by: AMOS SCIENTIFIC PTY.LTD 7 Gabrielle Court,Bayswater North VIC 3153 Melbourne , Australia Tel: +61-410190188 Fax: +61-410190188 ABN 37 159 778 140 www.amos-scientific.com...
