- Page 1 TEC 2800 （Version：AMOSTEC2800TCOP20150318） Thermal Console Operation Manual AMOS SCIENTIFIC PTY.LTD. ABN37 159 778 140 www.amos-scientific.com...
- Page 2 Foreword Thank you for purchasing our TEC2800 Thermal console. Presented in this 《Operation Manual》 are the functions and operation method support for the Embedding Center and the matters needing attention concerning safety. Please carefully read this manual before use so that you can understand its performance better and make full use of the functions.
-
Page 3: Table Of Contents
Contents Safety Matters 1、 ..........................1 1.1、S ........................1 AFETY ATTENTIONS 1.2、C ...................... 1 ONDITIONS OF INSTALLATION 1.3、D ........................1 ELIVERY INSPECTION Characteristics & Application 2、 ....................2 Main Structure 3、 ..........................2 Technical Parameters 4、 ........................2 Operation Explanation 5、... -
Page 4: Safety Matters
1. Safety Matters ● Please read these explicit rules. Act in violation of them can affect normal operation of the equipment, cause damage to the equipment or result in danger. Use 220VAC± 10% at 50HZ or 110VAC± 10% at 60HZ The input power supply must have good earthing The equipment should be installed far away from flammable and explosive objects Don’t open the equipment without authorization to prevent high voltage... -
Page 5: Characteristics & Application
2.Characteristics & Application TEC2800 Thermal console is support for Embedding Center. 3．Main Structure Display panel & Membrane Fig 1 Power switch Frame Thermal tank 4. Technical Parameters ⊙Capacity ：2.5Lt ⊙Working temperature: from ambient to 75℃ increments 1℃ ⊙Rated Power：335W ⊙Supply voltage: AC 220V± 10% 50Hz or AC 110V± 10% 60Hz ⊙Fuse: 220V/3A or 110V/5A ⊙Dimensions Width:... -
Page 6: Operation Explanation
5. Operation Explanation Indicate Lamp： Red----The machine is on the heating Green----The machine is on the temperature setting status. No light----The machine is on standby. LED： display the actual Temp.Set Increase temp.or set temp. Start/Standby Decrease Fig 2 Operation ● ●Temperature Set Connect to power supply and turn on the power switch(see Fig 1). - Page 7 c. Press again to exit the set status. d．Press to active the heating while the indicate light is on Red. After finished the setting, the LED screen will display the temperature degree increasing from 25℃ to 70℃. After reach to 70℃ , the indicate lamp will no light, the machine stop heating and the temperature degree decrease, but the machine will re-start to heating when the actual temperature is lower than 70℃.
-
Page 8: 6、Trouble Shooting
6、Trouble shooting Type Problem Possible causes Judge method Corrective action Power cord plug Plug in again Plug in again poor Take out the fuse to check its internal No display on LED screen no Fuse broken resistance by multimeter, if the value is Replace a new one the panel display... -
Page 9: 8、 Schematic Diagram Of Integrated Circuit
8、 Schematic Diagram of Integrated circuit ---6--- AEC380 Thermal Console AMOSAEC380TCOP20130318... -
Page 10: 9、Distribution Diagram Of Component
9、Distribution Diagram Of Component ---7--- AEC380 Thermal Console AMOSAEC380TCOP20130318... - Page 11 Standard accessories list Accessory Name Notes Thermal Console 1 unit Power Cord Fuse 2pcs Operation Manual...
- Page 12 Published by: AMOS SCIENTIFIC PTY.LTD 1 Prestige Dr Clayton South VIC 3169 Melbourne， Australia Tel: +61-410190188FAX:+61-3-98081503 ABN 37 159 778 140 www.amos-scientific.com...
