Samoa OMEGA 10:1 EXT Instruction Manual page 25

Pos. Code Description
95062 Screw
1
95063 Washer
2
7113 Covering
3
Front plate
4 7118
95065 Screw
5
95066 Washer
6
95086 Spring
7
95087 Ring nut
8
95085 Spring guide
9
95084 Roller pushing piston
10
95092 Roller
11
95091 Pin
12
95093 Rubber pad
13
95094 Washer
14
95095 Lock nut
15
95096 Washer
16
95097 Valve seat
17
95077 Spring
18
95075 O-ring
19
95076 Inversion movement valve
20
95073 Valve plate
21
95067 Hex socket set screw 3/4"
22
95068 Screw
23
95090 Fitting
24
95944 Coupling
25
GASKETS KIT MOTOR - CODE 40345
Pos. Description
O-ring
19
Inversion movement valve
20
Manifold gasket
30
Leather ring
35
Seal
36
Copper washer
37
O-ring
41
Gasket
45
Gas ring
46A
Leather ring
46B
ED. 02 - 02/2024 - Cod. 150210
Q.ty Pos. Code Description
95088 Extension
8 26
95099 Gas ring
8 27
95070 Manifold
1 28
96001 Plug
1 29
95072 Manifold gasket
4 30
95071 Seat valve plate
4 31
95074 Screw
2 32
95098 Bush
2 33
95078 Trip rod bearing
2 34
95079 Leather ring
2 35
95080 Seal
2 36
33031 Copper washer
2 37
7114 Motor cylinder
2 38
7112 Screw
2 39
95114 Washer
1 40
7116 O-ring
5 41
95135 Motor piston
1 42
95103 Motor rod
2 43
95104 Fitting
2 44
7111 Gasket
2 45
7120 Complete motor support
2 46
3314 Gas ring
1 46A
95082 Leather ring
4 46B
Plug
1 47 95229
95109 Support
1 48
MOTOR MOVEMENT INVERSION DEVICE -
CODE 40066
Q.ty Pos. Description
Roller pushing piston
2 10
Roller
2 11
Pin
2 12
O-ring
1 19
Inversion movement valve
1 20
Manifold gasket
1 30
1
1
1
1
EN
OMEGA 10:1 EXT
Q.ty
1
1
2
1
2
2
8
1
1
1
1
1
1
8
8
1
1
1
1
1
1
1
1
1
1
Q.ty
2
2
2
2
2
2
25
