General

2 General
2.1

Authorized use

•
The device is only designed for the use specified in this documentation.
•
Every other use is not authorized and is forbidden!
•
All relevant safety regulations, corresponding legal regulations, especially regulations of the
declaration of conformity, and additional local health and safety regulations must be observed.
Prior to every operation the user must ensure that:
•
The equipment is suited to the intended operation
•
the functioning and the working condition of the equipment is examined
•
the load is suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
•
The device SH-1000-MINI is only suitable for lifting, transporting and laying of dense concrete elements such as
natural stone, concrete, marble, granite slabs, steps, pipes, kerbstones, etc. with the corresponding suction
plates.
•
This device can be hung from any carrier/support frame (e.g. excavator) by means of load hook, chains, cables
and such like.
•
The load is additionally secured with the standard load securing chain.
•
Various suction plates can be fitted to the device (SH-1000-MINI) via a quick release locating pin, enabling it to
be used for many different purposes and with many different loads.
•
The carrying capacity/working load limit (WLL) of the device of 1000kg must not be exceeded!
This device is equipped with the following
safety devices:
Optional retrofit:
ATTENTION: The use of this device is only permitted in proximity to the ground (→ chapter
"Safety at work" and "Explanation of basic concepts").
52400020
•
Safety vacuum storage tank (vacuum tank volume 12,5 l).
•
Vacuum gauge.
•
Pressure relieve valve.
•
Acoustic warning device.
•
Load securing chain with chain box.
•
Optional traverse TRA (with load safety chain) for multiple
attachment of suction plates to the vacuum attachment.
•
Retrofitting of a hydraulic rotary head (facilitation for the
machine operator for exact positioning of the material to be laid)
