SN-SFP VoIP Gateway
Save button
Reboot button - saves your changes and reboots the device to apply the saved
changes.
7.1.5. Status
The Status subsection is designed to monitor in real time PCM and SIP channels,
call statistics and the system state of the module. The displayed settings of the
Status subsection are listed in the table below (Table 8).
Table 8. Status
Parameter
[CHANNEL MAP]
PCM
E1 port channels
SIP
SIP channels
User Manual
-
saves your changes.
Figure 14. SFP VoIP Gateway - Status
Descrip>on
Value
# -synchro ,meslot
$ -signalling ,meslot
L -LTEST board ,meslot
Page
31
of
47
