9.3 Operating display (6) (Fig. 3)
The operating display (6) is active when the engine is running.
9.4 Overload indicator (7) (Fig. 3)
The overload protection becomes active if the power consumption is too
high and switches off the 230 V ~ sockets (13).
1. Switch the device off as described in section 9.2.
2. Disconnect the power consumers from the device.
9.5 "RESET" button (12) (Fig. 3)
If the overload protection has been triggered and the overload indicator
(7) lights up red, the "RESET" button (12) can restore the output power
of the power generator/inverter. It is then not necessary to restart the
engine.
1. Press and hold the "RESET" button (12) for 1 second until the light
(red) is extinguished and the operation indicator (6) (green) illumi-
nates.
If the overload protection has not tripped, the "RESET" button (12) has
no effect.
9.6 Oil warning indicator (8) (Fig. 3)
The indicator activates when the oil level is too low and deactivates as
soon as the oil level is sufficient.
9.7 Automatic oil cut-off
The automatic oil cut-off system responds when there is too little engine
oil. The oil warning indicator (8) starts flashing when there is too little oil
in the engine. The indicator lamp starts to light up when the oil quantity
has not reached the safety quantity. The engine switches itself off after
a short time. It is not possible to start the engine until the engine oil has
been filled (see chapter 8.2).
