3.5" SBC with Rockchip RK3588 Processors, 8GB LPDDR4x Memory,
32GB eMMC NAND Flash, Single HDMI Input and Dual HDMI Output,
2.5GbE LAN, GbE LAN, USB 3.2 Gen 1, USB 2.0, 0°C ~60°C and RoHS
Quick Installation Guide
Package List
WAFER-RK3588 package includes the following items:
1 x WAFER-RK3588 single board computer
1 x QIG
WAFER-RK3588
Version 1.0
April 19, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAFER-RK3588 and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology WAFER-RK3588

  • Page 1 2.5GbE LAN, GbE LAN, USB 3.2 Gen 1, USB 2.0, 0°C ~60°C and RoHS WAFER-RK3588 Quick Installation Guide Version 1.0 April 19, 2023 Package List WAFER-RK3588 package includes the following items:  1 x WAFER-RK3588 single board computer  1 x QIG ©2023 Copyright by IEI Integration Corp.
  • Page 2: Specifications

    Specifications  Processor: Rockchip RK3588 (quad-core Cortex®-A76 + quad-core Cortex®A55)  GPU: Arm Mali-G610  NPU: 6 TOPS, supports int4, int8, int16, FP16, BF16 and TF32  RAM: On-board 8GB LPDDR4x  Flash: 32 GB eMMC NAND Flash for OS and IEI's boot loader ...
  • Page 3: Ordering Information

    Wi-Fi & Bluetooth module (2-stream 802.11ac, 2T2R, Bluetooth 5.0, RoHS) IEI Resource Download Center All the drivers and utility for the https://download.ieiworld.com WAFER-RK3588 are available on IEI Resource Download Center. Type WAFER-RK3588 and press Enter to find all the relevant software, utilities, and documentation.
  • Page 4: Jumpers Setting And Connectors

    Jumpers Setting and Connectors LABEL FUNCTION Audio line-out connector MIC1 Audio mic-in connector BAT_CN1 RTC battery connector LVDS1 LVDS connector M2_AE3 M.2 A/E key slot M2_BM1 M.2 B/M key slot MIPI_LCD1 MIPI DSI output connector CAM1 MIPI CSI connector PCIe x4 slot (x2 signal) Front panel connector SATA 6Gb/s connector SPL1, SPR1...
  • Page 5 LVDS1: LVDS Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCD_3V3 ODD_3N ODD_3P EVEN_0N EVEN_0P EVEN_1N EVEN_1P EVEN_CLKN ODD_0N EVEN_CLKP ODD_0P EVEN_2N ODD_1N EVEN_2P ODD_1P EVEN_3N ODD_CLKN EVEN_3P ODD_CLKP ODD_2N LED+ ODD_2P LED+ LED- LED- MIPI_LCD1: MIPI DSI Output Connector PIN NO. DESCRIPTION PIN NO.
  • Page 6 LED- LED- RESET DP3+ CAM1: MIPI CSI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDP2 LED- MDN2 LED+ RESET MDP3 DGND MDN3 DGND MDP1 MDN1 PWDN DGND MCLK DVDD_1V5 DOVDD_1V8 DGND AGND MDP0 AVDD_2V8 MDN0 DGND DGND SW2: Front Panel Connector PIN NO.
  • Page 7 CN4: SATA 6Gb/s Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RXP SATA_RXN SATA_TXN SATA_TXP SPL1: Speaker Connector (L) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPK_OUT_L_N SPK_OUT_L_P SPR1: Speaker Connector (R) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPK_OUT_R_N SPK_OUT_R_P CN1: Touch Panel Connector (LVDS) PIN NO.
  • Page 8: Board Layout: Jumper And Connector Locations

    COM1, COM2: UART Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB3: USB 2.0 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB 5V USB_D- USB_D+ USB_D+ USB_D- USB 5V Board Layout: Jumper and Connector Locations (Unit: mm)
