3.5" SBC Supports Intel® Celeron® J6412 on-board SoC with
8GB LPDDR4x, HDMI, DP, iDPM, Dual 2.5GbE LAN, M.2, PCIe x4 Slot,
SATA 6Gb/s, 10 COM, USB 3.2 Gen 2, iAUDIO, 0°C~60°C and RoHS
WAFER-EHL2-J6412
Quick Installation Guide
Package List
WAFER-EHL2-J6412 package includes the following items:
1 x WAFER-EHL2-J6412 single board computer
1 x Power cable
1 x SATA with power cable
1 x QIG
Version 1.0
July 14, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Related Manuals for IEI Technology WAFER-EHL2-J6412
Summary of Contents for IEI Technology WAFER-EHL2-J6412
- Page 1 SATA 6Gb/s, 10 COM, USB 3.2 Gen 2, iAUDIO, 0°C~60°C and RoHS WAFER-EHL2-J6412 Quick Installation Guide Version 1.0 July 14, 2023 Package List WAFER-EHL2-J6412 package includes the following items: 1 x WAFER-EHL2-J6412 single board computer 1 x Power cable ...
-
Page 2: Specifications
Specifications CPU: Intel® Celeron® J6412 onboard SoC (up to 2.6GHz, quad-core, 1.5M cache, TDP=10W) Support onboard Intel® Atom™ x6000 series / Pentium® / Celeron® processor (Elkhart Lake platform) Memory: Onboard 8GB 3200 MHz LPDDR4x, up to 16GB BIOS: AMI UEFI BIOS ... - Page 3 Front Panel: 1 x Power LED & HDD LED (1x6 pin, p=2.0) 1 x Power button (1x2 pin, p=2.0) 1 x Reset button (1x2 pin, p=2.0) Expansions: 1 x M.2 A key 2230 for Wi-Fi & Bluetooth (PCIe Gen3 x1 / USB 2.0 signal) 1 x M.2 B key 3042/2242 (PCIe Gen3 x2 / USB 2.0 signal) 1 x Onboard SIM card socket (hinge type) for M.2 B key...
-
Page 4: Ordering Information
Ordering Information WAFER-EHL2-J6412-R10: 3.5" SBC Supports Intel® Celeron® J6412 on-board SoC with 8GB LPDDR4x, HDMI, DP, iDPM, Dual 2.5GbE LAN, M.2, PCIe x4 Slot, SATA 6Gb/s, 10 COM, USB 3.2 Gen 2, iAUDIO, 0°C~60°C and RoHS CB-USB02A-RS: Dual-port USB cable with bracket, 300mm, p=2.0 ... -
Page 5: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION J_CMOS2 Clear CMOS button J_ATX_AT1 AT/ATX power mode setting jumper J_DNX1 DNX mode setting jumper J_FLASH1 Flash descriptor override setting jumper IAUDIO1 Audio connector for IEI AC-KIT-888S kit PWR1 ATX 12V power connector BAT1 Battery connector Buzzer connector CHASSIS1... - Page 6 M2_A1 M.2 A-key slot M2_B1 M.2 B-key slot PCIEX4_1 PCIe x4 slot (x2 signal) SIM1 SIM slot (solder side) IDPM1 IEI iDPM slot J_LAN1, J_LAN2 External 2.5GbE RJ-45 connectors USB_CONN1 External USB 3.2 Gen 2x1 Type-A connector External DisplayPort connector J_HDMI1 External dual HDMI connector J_CMOS2: Clear CMOS Button...
- Page 7 IAUDIO1: Internal Audio Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDA_CLK HDA_SYNC HDA_SDOUT HDA_SPKR HDA_SDIN HDA_RST# +12V PWR1: ATX 12V Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V BAT1: RTC Battery Connector DESCRIPTION DESCRIPTION VBATT BZ1: Buzzer Connector DESCRIPTION DESCRIPTION PC_BEEP...
- Page 8 J_DIO1: Digital Input/Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT5 DOUT4 DOUT3 DOUT2 DOUT1 DOUT0 DIN5 DIN4 DIN3 DIN2 DIN1 DIN0 F_PANEL1: Power LED & HDD LED Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWR_LED- HDD_LED+ PWR_LED+ HDD_LED- PWR_BTN1: Power Button Connector PIN NO.
- Page 9 COM5, COM6: RS-232/422/485 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION S_ATA1: SATA 6Gb/s Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX‐ SATA_TX+ SATA RX+ SATA_TX‐ SATA_PWR1: SATA Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION I2C1: I C Connector PIN NO.
- Page 10 SMB1: SMBus Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_CLK SMB_DATA JBIOS1: Flash SPI ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CLK SPI_CS# SPI_SI SPI_SO DEBUG_SPI1: EC Debug Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDICLK EDICS EDIDI EDIDO USB_CONN2, USB_CONN3: Internal USB 2.0 Connectors PIN NO.
- Page 11 Module Key PCIE_TX6+ PCIE_TX6- PCIE_RX6+ PCIE_RX6- CLK_M2_A+ CLK_M2_A- BTWIFI_SUS_CLK M.2_A_WAKE +V3.3A +V3.3A...
- Page 12 M2_B1: M.2 B-key Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V USB_D+ WWAN_DISABLE USB_D- Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key PCIE_RXN5 SIM_RST PCIE_RXP5 SIM_CLK SIM_CIO PCIE_TXN5 SIM_VCC PCIE_TXP5 PCIE_RXN4 PCIE_RXP4 PCIE_TXN4 PCIE_TXP4...
- Page 13 +3.3V +3.3V +3.3V SIM1: SIM Card Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION SIM_VCC SIM_RST SIM_CLOCK SIM_DATA J_LAN1, J_LAN2: External 2.5GbE RJ-45 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0P MDI2P MDI0N MDI2N MDI1P MDI3P MDI1N MDI3N DP1: External DP Connector PIN NO.
- Page 14 USB3_TX0+ USB3_TX1+ IEI Resource Download Center All the drivers and utility for the https://download.ieiworld.com WAFER-EHL2-J6412 are available on IEI Resource Download Center. Type WAFER-EHL2-J6412 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to view its content.
- Page 15 Board Layout: Jumper and Connector Locations (Unit: mm)
