KEYPAD
AP1
USER MANUAL
| CONFIGURATION MENU
51 Cycles through the Relay 2 functions:
• Alarm Out
• General Purpose (only activated by controller)
• Different Hold time. Activated when Relay 1 is activated but for a different
length of time. Used for controlling door holders.
• Slave to Relay 1. Is on whenever Relay 1 is on.
• Heater. IS active when temperature approach or are below freezing.
52 Relay 2 on time when the function different hold time is selected.
53 Alarm Time. The time that the buzzer will sound or Relay 1 will be active then
sound buzzer with alarm or Relay 2 functions as an alarm output. Triggered
an alarm state event in the AP1 occurs: Tamper, Door forced open, Door held
open.
60 Displays the help screen for command group 60 – TBD if needed
70 Displays the help screen for command group 70 – TBD if needed
80 Displays the help screen for command group 80 Factory Setup and testing
(not implemented)
90 Reserved. Used for Direct Test Mode.
Page - 19
