KEYPAD
AP1
USER MANUAL
| DISPLAY
2 x 16 Text Response
4 x 20 Text Response
Page - 16
This is the response sent to the VP class keypads with 2
x 16-character displays. All responses will be text and
specified in Storlogix. Note that the AP1 has no idea how
the controller responded and therefore the controller is
responsible for activating the relay. To see these responses
set the device type to a VP keypad in Storlogix.
This is the response sent to the APEX class keypads with
2 x 16-character displays. All responses will be text and
specified in Storlogix. Note that the AP1 has no idea how
the controller responded and therefore the controller is
responsible for activating the relay. To see these responses
set the device type to a APEX keypad in Storlogix.
