ELCOM REQ0 Y Series Operating And Assembly Instruction page 4

Set individual call push-button address/function
The menu entry Set individual call push-button
address/function is confirmed and flashes.
„ Confirm the call push-button to be set.
The menu entry flashes alternately with the
current address/function.
„ With / select the required address
or function for light push-button,
door release push-button or
„ Confirm set address/function with
The device applies the setting and returns to
the previous menu entry.
Display saved error codes
Audio insert and call push-button module errors
that occur during operation are stored in the the
error memory of the audio insert for diagnosis.
„ Select menu entry with button
confirm with
If no error code exists is displayed for 2
seconds and afterwards
If error codes are saved
the module address and the error code.
„ Press button / , to call up further error
codes if necessary.
„ Press button to return to menu entry
Error Error cause
code
Communication error
between audio insert
and call push-button
module. Once the
error has occurred 3
times, the system is
reset automatically
and the error code is
generated.
sticking call button
Writing of the call
push-button address
in the call push-button
module fails.
Table 2: Error codes and counter actions
i
The memory should only be deleted once 5
error codes have been stored, so that new error
codes can be saved.
i
Identical error codes are only saved once.
4 Elcom Kommunikation GmbH - Gottfried-Leibniz-Str.1 - D-74172 Neckarsulm - www.elcom.de -
Inserting door station
The system settings are complete.
„ Remove opening tool from housing.
„ Insert door station and press down until it clicks
audibly into place simultaneously at the top and
bottom if possible (Figure 12).
...
for
for no function.
.
.
/ and
.
flashes followed by
.
Dismantle call push-button module cover
Counter actions
During cleaning or replacement, the call push-but-
ton module cover can be dismantled from the front.
If the error per-
sists, the call
„ Lever up the interlocking cover strips (6) at
push-button
the top and bottom using the screwdriver and
module must be
remove (Figure 13).
replaced and
addressed.
Check call
push-button
module, and if
there is a defect,
replace and
address.
If the error per-
sists, the call
push-button
module must be
replaced and
addressed.
Figure 13: Removing the cover strips
„ Press up the call push-button module upper
part in the bottom lever opening with the screw-
driver and guide it forwards (Figure 14).
Figure 12: Insert door station
(6)
Figure 14: Dismantling the call push-button module
cover
(19) Call push-button module cover
i
Defective covers can only be replaced by cov-
ers with the same number of push-buttons.
„ Remove the module to be replaced and install
the new module in reverse order.
Open door station
„ Position the opening tool (15) at the bottom in
the middle and press up (Figure 15).
i
With two-series door stations, use the opening
tool in the middle under each series of call
push-buttons.
The door station will spring out of the bottom
interlocking mechanism forwards and can be
opened.
(19)
6LE000689A - 06/2015
