3.2 Board Topology
Front View
Ref. Description
U1
Raspberry Pi RP2040 Microcontroller
U3
N/A
U5
AT25SF128A-MHB-T 16MB Flash IC
U7
DSC6111HI2B-012.0000 MEMS Oscillator
LSM6DSOXTR 6-axis IMU with Machine Learning
U9
Core
DL1 Green Power On LED
DL3 RGB Common Anode LED
JP2
Analog Pin + D13 Pins
Back View
9 / 19
Front View of Arduino Nano RP2040 Connect Topology
Ref. Description
U2
U4
U6
U8
J1
DL2 Builtin Orange LED
PB1 Reset Button
JP3
Arduino® Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Ublox NINA-W102-00B Wi-Fi/Bluetooth® Module
ATECC608A-MAHDA-T Crypto IC
MP2322GQH Step-Down Buck Regulator
MP34DT06JTR MEMS Omnidirectional
Microphone IC
Male Micro USB Connector
Digital Pins
