5.5 Nina W102 SWD Pad
Pin
Function
1
TP_RST
2
TP_RX
3
TP_TX
4
TP_GPIO0
6 Mechanical Information
16 / 19
Type
Digital
Digital
Digital
Digital
Mechanical dimensions of Arduino Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Description
Reset
Serial Rx
Serial Tx
GPIO0
Modified: 07/05/2024
