1 The Board

1.1 Application Examples

The Nano RP2040 Connect can be adapted to a wide range of use cases thanks to the powerful microprocessor,
range of onboard sensors and Nano form factor. Possible applications include:
Edge Computing: Make use of the fast and high RAM microprocessor to run TinyML for anomaly detection, cough
detection, gesture analysis and more.
Wearable Devices: The small Nano footprint provides the possibility of providing machine learning to a range of
wearable devices including sports trackers and VR controllers.
Voice assistant: The Nano RP2040 Connect includes an omnidirectional microphone that can act as your personal
digital assistant and enable voice control for your projects.

1.2 Accessories

Micro USB cable
15-pin 2.54 mm male headers
15-pin 2.54 mm stackable headers

1.3 Related Products

Gravity: Nano I/O Shield

2 Ratings

2.1 Recommended Operating Conditions

Symbol Description
V
Input voltage from VIN pad
IN
V
Input voltage from USB connector
USB
V
3.3V output to user application
3V3
I
3.3V output current (including onboard IC)
3V3
V
Input high-level voltage
IH
V
Input low-level voltage
IL
I
Current at VDD-0.4 V, output set high
OH Max
I
Current at VSS+0.4 V, output set low
OL Max
V
Output high voltage, 8 mA
OH
V
Output low voltage, 8 mA
OL
T
Operating Temperature
OP
7 / 19 Arduino® Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Min Typ Max
4 5 20
4.75 5 5.25
3.25 3.3 3.35
- - 800
2.31 - 3.3
0 - 0.99
8
8
2.7 - 3.3
0 - 0.4
-20 - 80
Unit
V
V
V
mA
V
V
mA
mA
V
V
°C
