2.2 Thermal

Symbol Description
TST Storage Temperature
TOP Operating Temperature (excluding Wireless module)
TOPw Operating Temperature (including Wireless module)
2.3 Recommended Operating Conditions
Symbol Description
VIN Input voltage from VIN pad
VUSB Input voltage from USB connector
V3V3 3.3V output to user application
I3V3 3.3V output current available for user application
VIH Input high-level voltage
VIL Input low-level voltage
IOH Max Current at VDD-0.4 V, output set high
IOL Max Current at VSS+0.4 V, output set low
VOH Output high voltage, 8 mA
VOL Output low voltage, 8 mA
2.4 Power Consumption
Symbol Description
PBL Power consumption with busy loop
PLP Power consumption in low power mode
PMAX Maximum Power Consumption
3 Functional Overview
3.1 Board Topology
8 / 22 Arduino® Portenta H7 Lite / Rev. 01 - 09/09/2021
Arduino® Portenta H7 Lite
Min
-40
-40
-10
Min
4.5
4.5
-
2.31
0
2.7
0
Min Typ
TBC
TBC
TBC
Typ Max Unit
85 °C
85 °C
55 °C
Typ Max Unit
5 5.5 V
5 5.5 V
3.1 V
- 1000 mA
- 3.3 V
- 0.99 V
8 mA
8 mA
- 3.3 V
- 0.4 V
Max Unit
mW
mW
mW
