2.2 Power Consumption

Symbol Description
P
Power consumption with busy loop
BL
P
Power consumption in low power mode
LP
P
Maximum Power Consumption
MAX

3 Functional Overview

3.1 Block Diagram

8 / 19
Block Diagram of Arduino Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Arduino® Nano RP2040 Connect
Min Typ Max
TBC
TBC
TBC
Unit
mW
mW
mW
