Opitec Hobbyfix Mini-Holli Manual page 3

1
1) Press out the pre-cut parts
4
4) Cut the dowel with a craft knife
into 1 x 88mm and 2x 145mm
7
7) Apply the glue as shown and
fold the fuselage together
10) Glue the wings, tailplane in
D102076#1
2
2) Fold the fuselage along the
middle line
5
5) Glue the dowels in the marked
places
8
8) Now bend the wings and tail-
plane into a rounded shape
over a table edge
10
place and leave to dry
3
3) Glue the washer in the nose
6
6) Glue the tail fin in position
9
9) Insert the rounded tailplane in
the pre cut slot
11
11)Fold the wing tips up as shown
3
